PY2793 is a hygienic pressure sensor with integrated display and flush process connection. It provides a −1…25 bar pressure range for demanding food and beverage applications. The device combines two programmable switching outputs with a scalable 4–20 mA analogue output. IO-Link provides advanced parameterisation and digital process information. Its stainless-steel hygienic construction is designed for high-pressure cleaning and sanitary processing. PY2793 is suitable for tanks, pipes, pumps and hygienic process systems.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PY2793 is designed for hygienic pressure measurement with integrated local display. Its flush process connection helps minimize product accumulation and dead space. Two switching outputs provide independent pressure-control functions. The scalable analogue output enables continuous pressure transmission to automation systems. IO-Link supports digital configuration and diagnostics. The sensor is suitable for food, beverage and sanitary manufacturing environments.
The four-digit display provides clear local pressure information. Switching LEDs provide status feedback. The stainless-steel housing supports hygienic installation. The flush Aseptoflex Vario connection is designed for sanitary process systems. High protection supports washdown and cleaning procedures. The display and electronic functions provide convenient operation during production and maintenance.
−1…25 bar range
Integrated digital display
Flush hygienic process connection
Two switching outputs
One analogue output
4–20 mA
IO-Link
Scalable analogue output
PNP/NPN outputs
Stainless-steel construction
High-pressure cleaning resistance
Hygienic design
Digital diagnostics
Local parameterisation
Process monitoring
Food processing
Beverage production
Dairy processing
Breweries
Hygienic tanks
Process piping
CIP systems
SIP systems
Filling systems
Pump monitoring
Pressure control
Product pressure monitoring
Quality control
Process automation
Sanitary machinery
| Specification | Details |
|---|---|
| Product model | PY2793 |
| Order code | PI-025-REA01-MFRKG/US/ /P |
| Product type | Hygienic pressure sensor with display |
| Measuring range | −1…25 bar |
| Pressure type | Relative |
| Switching outputs | 2 |
| Analogue output | 1 |
| Analogue signal | 4–20 mA |
| Analogue scaling | Configurable |
| Output logic | PNP/NPN |
| Display | 4-digit |
| Display colour | Red/green |
| Display units | bar / psi / MPa / %FS |
| IO-Link | Yes |
| Supply | 18–32 V DC / 20–32 V DC depending wiring |
| Process connection | G 1 external / Aseptoflex Vario |
| Housing | Stainless steel |
| Wetted parts | Hygienic stainless steel / ceramic / PTFE |
| Protection | IP67/IP68/IP69K |
| Switching frequency | Up to 125 Hz |
| Max switching current | 250 mA |
| Accuracy | <±0.2% span switch point |
| Repeatability | <±0.1% span |
| Long-term stability | <±0.1% span/year |
| Parameterisation | Buttons / IO-Link |
| Application | Food and beverage |
