PV8001 is an intelligent pressure switch designed for pressure and temperature monitoring in industrial systems. It provides a 0–250 bar pressure measuring range. The device supports two programmable digital outputs and IO-Link communication. Its integrated temperature-monitoring capability provides additional process information. The robust stainless-steel construction supports demanding industrial operation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PV8001 provides pressure monitoring up to 250 bar. The device can also provide temperature information through its IO-Link process data. Pressure switching thresholds can be configured according to application requirements. Digital communication enables remote configuration and diagnostics. This combination allows pressure and thermal conditions to be monitored using one sensor.
The sensor uses a metallic thin-film measuring technology. Its G1/4 process connection provides secure installation in compatible pressure systems. Stainless-steel wetted materials provide mechanical durability. IP67/IP69K protection supports demanding industrial conditions. Shock and vibration resistance make the sensor suitable for machinery installations.
PV8001 is suitable for hydraulic systems where both pressure and temperature are important. It can monitor pumps, hydraulic power units and process pressure. IO-Link supports PLC integration and predictive-maintenance strategies. Pressure and temperature peak information can support machine diagnostics. The compact design reduces installation requirements.
0…250 bar range
Integrated temperature monitoring
Two digital outputs
IO-Link communication
Pressure data transmission
Temperature data transmission
Programmable switching points
Hysteresis mode
Window mode
Adjustable damping
Switching delays
Metallic thin-film cell
G1/4 process connection
M5 internal thread
Stainless-steel construction
Fast response
IP67/IP69K
Shock resistance
Vibration resistance
Diagnostic data
Hydraulic systems
Hydraulic pumps
Power units
Pressure monitoring
Temperature monitoring
Machine protection
Industrial automation
PLC systems
Process monitoring
Condition monitoring
Predictive maintenance
Machine diagnostics
Pressure alarms
Temperature alarms
Equipment protection
| Specification | Details |
|---|---|
| Model | PV8001 |
| Order code | PV-250-SEG14-UFRVG/US |
| Pressure type | Relative |
| Pressure range | 0…250 bar |
| Equivalent | 0…3625 psi |
| Temperature monitoring | Yes |
| Temperature range | −40…90 °C family |
| Measuring element | Metallic thin-film |
| Digital outputs | 2 |
| Communication | IO-Link |
| Output logic | Configurable |
| Process connection | G1/4 |
| Auxiliary thread | M5 |
| Supply | 18…30 V DC |
| Current consumption | <15 mA |
| Switching current | 100 mA |
| Response | <3 ms |
| Pressure resolution | 0.2 bar class |
| Temperature resolution | 0.2 K class |
| Repeatability | < ±0.05 % span |
| Linearity | < ±0.1 % BFSL / < ±0.2 % LS |
| Hysteresis | < ±0.2 % span |
| Protection | IP67/IP69K |
| Application | Industrial pressure/temperature monitoring |
