PV7603 is a compact pressure switch designed for low-pressure industrial applications. It provides a 0–25 bar measuring range with programmable switching outputs. The sensor uses a 1/4-inch NPT connection for compatible pressure systems. IO-Link provides digital configuration and diagnostic functions. Its robust stainless-steel construction supports reliable operation in automated equipment.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PV7603 provides accurate monitoring across a 0–25 bar pressure range. Set and reset points can be configured for specific machine requirements. Hysteresis and window switching provide flexible control. Adjustable damping helps improve switching stability in fluctuating systems. IO-Link allows digital parameterisation without manual sensor adjustment.
The metallic thin-film measuring cell provides stable pressure sensing. The stainless-steel body supports industrial durability. The sensor can withstand mechanical shock and vibration. Electrical protection functions help protect the electronics. Its compact housing makes it suitable for installations with limited space.
PV7603 is suitable for low-pressure hydraulic and pneumatic systems. It can monitor pumps, compressors and automated pressure circuits. Programmable outputs can control alarms and machine-protection functions. IO-Link supports connection to intelligent automation networks. Its compact design simplifies installation near pressure sources.
0…25 bar range
1/4" NPT connection
Two digital outputs
IO-Link communication
PNP/NPN operation
Programmable NO/NC
Adjustable switching points
Adjustable reset points
Hysteresis mode
Window mode
Adjustable damping
Switching delays
Metallic thin-film cell
Stainless-steel housing
Fast response
Short-circuit protection
Overload protection
Reverse-polarity protection
IP67/IP69K
Industrial-grade construction
Low-pressure hydraulics
Pneumatic systems
Pump monitoring
Compressor systems
Pressure alarms
Machine protection
Industrial automation
Process monitoring
Machine diagnostics
Condition monitoring
PLC systems
Equipment protection
Preventive maintenance
Packaging machines
IO-Link automation
| Specification | Details |
|---|---|
| Model | PV7603 |
| Order code | PV-025-SEN14-UFRVG/US |
| Pressure type | Relative |
| Measuring range | 0…25 bar |
| Equivalent | 0…362.6 psi |
| Measuring element | Metallic thin-film |
| Digital outputs | 2 |
| Communication | IO-Link |
| Electrical design | PNP/NPN |
| Output function | NO/NC programmable |
| Process connection | 1/4" NPT |
| Auxiliary thread | M5 |
| Supply voltage | 18…30 V DC |
| Current consumption | <15 mA |
| Switching current | 100 mA |
| Switching frequency | <170 Hz |
| Response time | <3 ms |
| Accuracy | < ±0.5 % span |
| Repeatability | < ±0.05 % span |
| Linearity | < ±0.1 % BFSL / < ±0.2 % LS |
| Hysteresis | < ±0.2 % span |
| Long-term stability | < ±0.1 % span |
| Protection | IP67/IP69K |
| Application | Industrial pressure monitoring |
