PV7003 is an intelligent pressure switch designed for low-pressure hydraulic and pneumatic applications. It provides a −1 to 25 bar measuring range for pressure and vacuum monitoring. Two configurable switching outputs provide flexible machine-control functionality. IO-Link communication allows digital parameterisation and diagnostic access. Its compact stainless-steel construction supports reliable operation in demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PV7003 can monitor both positive pressure and vacuum conditions. Its −1 to 25 bar range makes it suitable for applications requiring wider low-pressure monitoring. Switching thresholds can be programmed to suit different machine sequences. Hysteresis and window functions provide additional control flexibility. IO-Link allows pressure parameters to be changed without manually adjusting the sensor.
The metallic thin-film measuring cell provides dependable pressure measurement. Stainless-steel construction supports resistance to mechanical stress and industrial conditions. Integrated protection functions help prevent electrical damage from common faults. The compact housing allows installation close to pressure sources. The sensor is suitable for repeated pressure cycles in automated equipment.
PV7003 can be used in pneumatic systems, vacuum circuits and low-pressure hydraulics. It can monitor pressure in pumps, compressors and automated machinery. Programmable outputs can activate alarms or protective functions. IO-Link provides useful diagnostic information for maintenance teams. The sensor is well suited to automated machines requiring configurable low-pressure monitoring.
−1…25 bar measuring range
Pressure and vacuum measurement
Two digital outputs
IO-Link communication
PNP/NPN design
Programmable NO/NC outputs
Configurable switching points
Configurable reset points
Hysteresis function
Window function
Adjustable damping
Switching delay
Metallic thin-film cell
Stainless-steel construction
Fast response
Short-circuit protection
Overload protection
Reverse-polarity protection
IP67/IP69K
Long service life
Pneumatic systems
Vacuum monitoring
Low-pressure hydraulics
Compressor systems
Pump monitoring
Pressure alarms
Vacuum alarms
Machine protection
Industrial automation
Process monitoring
Packaging machinery
Material handling equipment
Machine diagnostics
Condition monitoring
PLC automation
| Specification | Details |
|---|---|
| Model | PV7003 |
| Product type | Pressure switch with IO-Link |
| Order code | PV-025-SEG14-UFRVG/US |
| Pressure type | Relative / vacuum |
| Measuring range | −1…25 bar |
| Equivalent range | −14.5…362.6 psi |
| Measuring cell | Metallic thin-film |
| Digital outputs | 2 |
| Communication | IO-Link |
| Electrical design | PNP/NPN |
| Output logic | NO/NC programmable |
| Process connection | G 1/4 |
| Auxiliary thread | M5 |
| Supply voltage | 18…30 V DC |
| Current consumption | <15 mA |
| Switching current | 100 mA |
| Switching frequency | <170 Hz |
| Response time | <3 ms |
| Switch-point accuracy | < ±0.5 % span |
| Repeatability | < ±0.05 % span |
| Linearity | < ±0.1 % BFSL / < ±0.2 % LS |
| Hysteresis | < ±0.2 % span |
| Protection | IP67/IP69K |
| Communication revision | IO-Link 1.1 |
