PU8712 is a compact pressure transmitter designed for 0–160 bar mobile hydraulic applications. It provides a 0.5–4.5 V analogue signal for pressure monitoring and machine control. Its stainless-steel construction supports reliable operation in demanding conditions. The compact cylindrical design enables flexible installation. The transmitter is suitable for mobile hydraulic equipment requiring dependable pressure feedback.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PU8712 continuously measures relative pressure up to 160 bar. The analogue output provides proportional pressure feedback to controllers. Fast response supports dynamic hydraulic pressure monitoring. High repeatability helps maintain consistent measurement. The fixed range simplifies machine integration.
The transmitter uses robust stainless-steel pressure measuring technology. Its design is intended for environments with vibration and shock. IP67/IP69K protection supports demanding mobile applications. Electrical protection functions improve reliability. The compact body supports installation near hydraulic pressure sources.
PU8712 is suitable for mobile hydraulic machinery and pressure-control systems. It can be installed on pumps and hydraulic power units. Pressure feedback can support diagnostics and protective functions. Construction and agricultural machinery can use the transmitter. The analogue signal integrates with compatible controller electronics.
0–160 bar
0.5–4.5 V output
Relative pressure
G 1/4 process connection
DEUTSCH connector
Stainless-steel measuring cell
Compact housing
Fast response
High repeatability
Low hysteresis
Long-term stability
IP67/IP69K
Shock resistance
Vibration resistance
Overload protection
Short-circuit protection
Reverse-polarity protection
Mobile-machine design
Analogue controller integration
Pressure monitoring
Mobile hydraulics
Construction machinery
Agricultural equipment
Off-highway vehicles
Hydraulic pumps
Power units
Pressure monitoring
Pressure control
Machine diagnostics
Pressure alarms
Equipment protection
Preventive maintenance
Mobile automation
Industrial automation
Machine control
| Specification | Details |
|---|---|
| Model | PU8712 |
| Order code | PU-160-SEG14-V-DVG/DE |
| Pressure type | Relative |
| Measuring range | 0…160 bar |
| Equivalent | 0…2320 psi |
| Output | 0.5…4.5 V |
| Process connection | G 1/4 male |
| Electrical connection | DEUTSCH |
| Supply | 8…32 V DC family |
| Measuring cell | Thin-film |
| Cell material | Stainless steel |
| Housing | Cylindrical |
| Response | Approx. 2 ms |
| Repeatability | < ±0.05 % span |
| Characteristics deviation | < ±0.8 % span |
| Linearity | < ±0.25 % BFSL / < ±0.5 % LS |
| Hysteresis | < ±0.2 % span |
| Long-term stability | < ±0.1 % span |
| Medium temperature | −40…125 °C |
| Ambient temperature | −40…100 °C |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Application | Mobile hydraulics |
