PU8504 is a compact 0–10 bar pressure transmitter designed for low-pressure applications. It provides a 0.5–4.5 V analogue signal for machine-control systems. The transmitter uses robust stainless-steel pressure measuring technology. Its compact housing supports installation in restricted spaces. It is suitable for mobile hydraulic and pneumatic equipment.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PU8504 continuously measures relative pressure up to 10 bar. The proportional voltage output provides continuous pressure feedback. Fast response allows pressure changes to be detected quickly. High repeatability supports stable control signals. The fixed measuring range simplifies system integration.
The compact stainless-steel construction is designed for demanding mobile environments. High shock and vibration resistance support reliable operation. IP67/IP69K protection helps protect the transmitter from environmental conditions. Electrical protection supports dependable operation. The compact design allows easy installation close to the pressure source.
PU8504 is suitable for pneumatic systems and low-pressure hydraulics. It can be used with pumps, compressors and machine-control circuits. The pressure signal can support machine diagnostics and alarm functions. Agricultural and construction machinery can benefit from its compact design. The transmitter integrates with suitable analogue controller inputs.
0–10 bar
0.5–4.5 V output
Relative pressure
G 1/4 connection
M12 connector
Stainless-steel measuring cell
Compact housing
Fast response
High repeatability
Low hysteresis
Long-term stability
IP67/IP69K
Shock resistance
Vibration resistance
Overload protection
Short-circuit protection
Reverse-polarity protection
Mobile application
Controller integration
Pressure monitoring
Pneumatic systems
Low-pressure hydraulics
Mobile machinery
Construction machinery
Agricultural equipment
Pumps
Compressors
Pressure monitoring
Pressure alarms
Machine diagnostics
Equipment protection
Preventive maintenance
Mobile automation
Industrial automation
Machine control
| Specification | Details |
|---|---|
| Model | PU8504 |
| Order code | PU-010-SEG14-C-DVG/US |
| Pressure type | Relative |
| Measuring range | 0…10 bar |
| Equivalent | 0…145 psi |
| Output | 0.5…4.5 V |
| Process connection | G 1/4 male |
| Electrical connection | M12 |
| Supply | 8…32 V DC |
| Current consumption | <12 mA |
| Load resistance | ≥2000 Ω |
| Measuring cell | Thin-film |
| Cell material | Stainless steel |
| Response | Approx. 2 ms |
| Repeatability | < ±0.05 % span |
| Characteristics deviation | < ±0.8 % span |
| Linearity | < ±0.25 % BFSL / < ±0.5 % LS |
| Hysteresis | < ±0.2 % span |
| Long-term stability | < ±0.1 % span |
| Medium temperature | −40…125 °C |
| Ambient temperature | −40…100 °C |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Application | Mobile hydraulics |
