PU502E is a compact pressure transmitter designed for accurate pressure monitoring in mobile machinery and hydraulic systems. It provides a 0 to 100 bar measuring range for medium-pressure applications. The robust stainless-steel construction provides high resistance to mechanical shock and vibration. Its compact housing allows installation in areas where mounting space is restricted. The transmitter provides stable, repeatable pressure measurement for continuous machine operation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PU502E is designed to reliably detect system pressure in mobile machines and associated hydraulic circuits. The transmitter uses a G 1/4 external threaded process connection for secure pressure-port installation. Its analogue output provides a proportional electrical signal to compatible control equipment. The compact cylindrical housing supports installation close to hydraulic pressure sources. High measurement repeatability and low characteristic deviation contribute to dependable system monitoring.
PU502E measures relative pressure from 0 to 100 bar, equivalent to 0 to 1450 psi. Its analogue output responds rapidly to changing pressure conditions with a 2 ms step response time. Repeatability is specified at less than ±0.05% of span under defined conditions. Linearity deviation is below ±0.25% BFSL and hysteresis deviation is below ±0.2%. These characteristics make the transmitter suitable for pressure control, diagnostics and machine protection.
PU502E uses a cylindrical stainless-steel housing with dimensions of approximately 19 mm diameter and 66 mm length. The pressure-contact components are manufactured from stainless steel 17-4 PH for demanding applications. The transmitter is designed for a minimum of 60 million pressure cycles at 1.2 times nominal pressure. Its shock resistance is specified at 500 g and vibration resistance at 20 g. IP67 and IP69K protection supports reliable use in harsh mobile-machine environments.
0…100 bar measuring range
Relative pressure measurement
0.5…4.5 V analogue output
G 1/4 external threaded connection
M12 electrical connector
8…32 V DC supply
Compact cylindrical housing
Stainless-steel construction
17-4 PH stainless-steel wetted parts
2 ms analogue response
Less than ±0.05% repeatability
Less than ±0.25% BFSL linearity deviation
Less than ±0.2% hysteresis
Long-term stability below ±0.1%
60 million minimum pressure cycles
500 g shock resistance
20 g vibration resistance
IP67 protection
IP69K protection
Integrated restrictor
Overload protection
Short-circuit protection
Reverse-polarity protection
Mobile hydraulic systems
Construction machinery
Agricultural machinery
Off-highway equipment
Hydraulic power units
Hydraulic pumps
Pressure monitoring
Machine control
Pressure diagnostics
Pressure alarm systems
Hydraulic equipment protection
Preventive maintenance
PLC automation
Mobile machine electronics
Industrial hydraulic equipment
| Specification | Details |
|---|---|
| Model | PU502E |
| Order code | PU-100-SEG14-C-DVG/US |
| Product type | Pressure transmitter |
| Application | Mobile applications |
| Pressure type | Relative pressure |
| Measuring range | 0…100 bar |
| Equivalent range | 0…1450 psi |
| Equivalent range | 0…10 MPa |
| Analogue output | 0.5…4.5 V |
| Analogue outputs | 1 |
| Supply voltage | 8…32 V DC |
| Current consumption | <12 mA |
| Process connection | G 1/4 external thread |
| Process connection standard | DIN EN ISO 1179-2 |
| Electrical connection | M12 |
| Connector coding | A-coded |
| Maximum cable length | 30 m |
| Minimum load resistance | 2000 Ω |
| Response time | 2 ms |
| Repeatability | < ±0.05% span |
| Characteristics deviation | < ±0.8% span |
| Linearity | < ±0.25% BFSL / < ±0.5% LS |
| Hysteresis | < ±0.2% span |
| Long-term stability | < ±0.1% / 6 months |
| Temperature coefficient | < ±0.1% / 10 K in normal range |
| Ambient temperature | −40…100 °C |
| Storage temperature | −40…100 °C |
| Protection | IP67 / IP69K |
| Shock resistance | 500 g / 1 ms |
| Vibration resistance | 20 g / 10…2000 Hz |
| Housing | Cylindrical |
| Dimensions | Ø19 × 66 mm |
| Wetted material | Stainless steel 17-4 PH |
| Pressure cycles | 60 million minimum |
| Process seal | HNBR |
| Restrictor | Integrated |
