PU501E is a compact pressure transmitter designed for reliable pressure measurement in mobile machinery and hydraulic systems. It provides a 0 to 250 bar measuring range for monitoring demanding pressure conditions. The robust stainless-steel housing offers high resistance to shock and vibration during machine operation. Its compact cylindrical construction is suitable for installations where available space is limited. The transmitter is designed for stable and repeatable pressure measurement over long operating periods.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PU501E is designed to continuously detect system pressure in mobile machines and hydraulic equipment. The transmitter uses a G 1/4 external threaded process connection for secure installation. Its analogue voltage output can be connected to suitable machine controllers and monitoring systems. High repeatability and low linearity error support consistent pressure information. The device is particularly suitable for demanding mobile applications requiring robust pressure sensing.
The transmitter measures relative pressure across a 0 to 250 bar range. Its 0.5 to 4.5 V analogue output provides a proportional signal for electronic control systems. A 2 ms analogue step response allows fast detection of pressure changes. Repeatability is specified below ±0.05% of span under defined temperature conditions. Long-term stability and low hysteresis help maintain dependable pressure measurement during extended operation.
PU501E features a compact cylindrical stainless-steel housing measuring approximately 19 mm in diameter and 66 mm in length. The wetted components use stainless steel 17-4 PH material for pressure-contact durability. The transmitter is designed for more than 60 million pressure cycles at 1.2 times nominal pressure. Shock resistance reaches 500 g and vibration resistance reaches 20 g under specified test conditions. IP67 and IP69K protection supports operation in demanding mobile-machine environments.
0…250 bar measuring range
Relative pressure measurement
0.5…4.5 V analogue output
G 1/4 external threaded process connection
M12 electrical connector
8…32 V DC supply
Compact cylindrical stainless-steel housing
17-4 PH stainless-steel wetted parts
2 ms analogue response time
Less than ±0.05% repeatability
Less than ±0.25% BFSL linearity deviation
Less than ±0.2% hysteresis deviation
Long-term stability below ±0.1% per 6 months
More than 60 million pressure cycles
500 g shock resistance
20 g vibration resistance
IP67 protection
IP69K protection
Integrated restrictor element
Overload protection
Short-circuit protection
Reverse-polarity protection
Mobile hydraulic machinery
Construction equipment
Agricultural machinery
Off-highway vehicles
Hydraulic power units
Hydraulic pumps
Hydraulic pressure monitoring
Machine control systems
Pressure diagnostics
Pressure alarm systems
Equipment protection
Preventive maintenance
PLC-based machine automation
Mobile machine electronics
Industrial hydraulic systems
| Specification | Details |
|---|---|
| Model | PU501E |
| Order code | PU-250-SEG14-C-DVG/US |
| Product type | Pressure transmitter |
| Application | Mobile applications |
| Pressure type | Relative pressure |
| Measuring range | 0…250 bar |
| Measuring range | 0…3625 psi |
| Measuring range | 0…25 MPa |
| Analogue output | 0.5…4.5 V |
| Number of analogue outputs | 1 |
| Supply voltage | 8…32 V DC |
| Current consumption | <12 mA |
| Process connection | G 1/4 external thread |
| Connection standard | DIN EN ISO 1179-2 |
| Electrical connection | M12, A-coded |
| Maximum cable length | 30 m |
| Minimum load resistance | 2000 Ω |
| Response time | 2 ms |
| Repeatability | < ±0.05% span |
| Linearity deviation | < ±0.25% BFSL / < ±0.5% LS |
| Hysteresis deviation | < ±0.2% span |
| Long-term stability | < ±0.1% span / 6 months |
| Ambient temperature | −40…100 °C |
| Storage temperature | −40…100 °C |
| Protection rating | IP67 / IP69K |
| Shock resistance | 500 g / 1 ms |
| Vibration resistance | 20 g / 10…2000 Hz |
| Housing | Cylindrical stainless steel |
| Dimensions | Ø19 × 66 mm |
| Wetted material | Stainless steel 17-4 PH |
| Pressure cycles | 60 million minimum |
| Tightening torque | 25…35 Nm |
| Process seal | HNBR |
| Integrated restrictor | Yes |
