PT9553 is a compact 0–25 bar pressure transmitter designed for low-pressure mobile and industrial applications. It provides a 0–10 V analogue output for machine-control systems. The stainless-steel construction provides reliable mechanical performance. Its G 1/4 process connection enables secure installation. The compact design is useful for pressure monitoring in restricted machine spaces.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PT9553 measures relative pressure continuously and converts the measurement into a proportional voltage signal. The 25 bar range is suitable for low-pressure hydraulic and pneumatic systems. The transmitter can be connected to PLC analogue input modules. Its robust housing supports vibration-prone environments. It is suitable for monitoring, diagnostics and pressure control.
0…25 bar
0–10 V
Relative pressure
G 1/4 process connection
M12 connector
16–36 V DC
Stainless steel
Compact design
High repeatability
Low hysteresis
Low linearity deviation
Long-term stability
IP67/IP69K
High shock resistance
High vibration resistance
Liquid/gas compatibility
Pressure overload capability
PLC compatible
Analogue voltage output
Mobile application
Pneumatic systems
Low-pressure hydraulics
Mobile machinery
Industrial machinery
Pumps
Compressors
Pressure monitoring
Pressure alarms
Machine diagnostics
Equipment protection
Preventive maintenance
PLC automation
Process control
Mobile machine control
Industrial automation
| Specification | Details |
|---|---|
| Model | PT9553 |
| Order code | PT-025-SBG14-B-DVG/US//W |
| Pressure type | Relative |
| Measuring range | 0…25 bar |
| Equivalent | 0…362 psi |
| Output | 0…10 V |
| Process connection | G 1/4 |
| Connector | M12 |
| Supply | 16…36 V DC |
| Current consumption | <6 mA |
| Housing | Stainless steel |
| Media | Liquids/gases |
| Medium temperature | −25…90 °C |
| Pressure rating | High |
| Burst capability | High |
| Repeatability | < ±0.1 % |
| Characteristics deviation | < ±1.0 % |
| Linearity | < ±0.25 % BFSL |
| Hysteresis | < ±0.2 % |
| Long-term stability | < ±0.1 % |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Application | Mobile/industrial |
