PT9552 is a compact 0–100 bar pressure transmitter designed for reliable mobile pressure measurement. It provides a 0–10 V analogue output for machine controllers and monitoring systems. Its stainless-steel housing provides high mechanical durability. The G 1/4 process connection enables secure installation. The transmitter is suitable for hydraulic, pneumatic and industrial pressure applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PT9552 provides continuous relative pressure measurement for mobile and industrial systems. The 100 bar range is suitable for medium-pressure hydraulic applications. The analogue voltage output enables easy integration with compatible control equipment. Its compact design supports installation in restricted spaces. High repeatability contributes to stable pressure measurement.
0…100 bar
0–10 V
Relative pressure
G 1/4 thread
M12 connector
16–36 V DC
Stainless steel
Compact body
High repeatability
Low linearity error
Low hysteresis
Long-term stability
IP67/IP69K
High shock resistance
High vibration resistance
Liquid/gas compatible
Pressure overload capability
PLC compatible
Machine diagnostics
Mobile-machine design
Hydraulic systems
Mobile machinery
Construction equipment
Agricultural equipment
Pumps
Compressors
Hydraulic power units
Industrial machinery
Pressure monitoring
Pressure control
Machine diagnostics
Preventive maintenance
Equipment protection
PLC automation
Mobile control
| Specification | Details |
|---|---|
| Model | PT9552 |
| Order code | PT-100-SBG14-B-DVG/US//W |
| Pressure type | Relative |
| Measuring range | 0…100 bar |
| Equivalent | 0…1450 psi |
| Output | 0…10 V |
| Process connection | G 1/4 |
| Connector | M12 |
| Supply | 16…36 V DC |
| Current consumption | <6 mA |
| Housing | Stainless steel |
| Media | Liquids/gases |
| Medium temperature | −25…90 °C |
| Pressure rating | High |
| Burst capability | High |
| Repeatability | < ±0.1 % |
| Characteristics deviation | < ±1.0 % |
| Linearity | < ±0.25 % BFSL |
| Hysteresis | < ±0.2 % |
| Long-term stability | < ±0.1 % |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Application | Mobile/industrial |
