PT9550 is a compact pressure transmitter designed for mobile applications and demanding pressure monitoring. It provides a 0–400 bar measuring range and a 0–10 V analogue output. The transmitter uses a robust stainless-steel housing and G 1/4 process connection. Its design provides high resistance to shock and vibration. The compact body is suitable for pressure measurement where installation space is limited.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PT9550 provides continuous relative pressure measurement for mobile hydraulic applications. The 0–10 V output enables connection to compatible control and monitoring systems. The transmitter operates from a 16–36 V DC supply. Its compact construction provides reliable installation in machinery. The transmitter is suitable for liquids and gases and provides high pressure capability.
0…400 bar
0–10 V output
Relative pressure
G 1/4 external thread
M12 electrical connection
Stainless steel
Compact body
16–36 V DC
High shock resistance
High vibration resistance
High repeatability
Low linearity deviation
Low hysteresis
Long-term stability
IP67/IP69K
600 bar pressure rating
1600 bar minimum burst pressure
Mobile application
PLC compatible
Mobile hydraulics
Construction machinery
Agricultural machinery
Off-highway vehicles
Hydraulic power units
Pumps
Compressors
Pressure control
Machine diagnostics
Pressure alarms
Equipment protection
Preventive maintenance
PLC automation
Mobile control
Industrial hydraulics
| Specification | Details |
|---|---|
| Model | PT9550 |
| Order code | PT-400-SBG14-B-DVG/US//W |
| Pressure type | Relative |
| Measuring range | 0…400 bar |
| Equivalent | 0…5800 psi / 0…40 MPa |
| Output | 0…10 V |
| Process connection | G 1/4 external |
| Electrical connection | M12 |
| Supply voltage | 16…36 V DC |
| Current consumption | <6 mA |
| Housing | Stainless steel |
| Media | Liquids/gases |
| Medium temperature | −25…90 °C |
| Pressure rating | 600 bar |
| Burst pressure | 1600 bar |
| Repeatability | < ±0.1 % span |
| Characteristics deviation | < ±1.0 % span |
| Linearity | < ±0.25 % BFSL |
| Hysteresis | < ±0.2 % |
| Long-term stability | < ±0.1 % |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Application | Mobile machinery |
