PT9543 is a compact 0–25 bar pressure transmitter designed for low-pressure industrial applications. It provides a 0–10 V analogue output for compatible control systems. The stainless-steel housing supports reliable operation in industrial environments. Its G 1/4 process connection provides secure installation. The transmitter is suitable for pumps, compressors, pneumatic systems and process equipment.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PT9543 provides continuous relative pressure measurement across a 0–25 bar range. Its voltage output allows integration with analogue PLC input modules. The compact construction supports installation in restricted machine spaces. High repeatability helps maintain consistent process information. The transmitter is designed for long-term pressure monitoring.
0…25 bar
0–10 V
Relative pressure
G 1/4 external thread
16–36 V DC
Stainless steel
Compact construction
High repeatability
Low hysteresis
Low linearity error
Long-term stability
High shock resistance
High vibration resistance
IP67/IP69K
Liquid/gas compatible
Analogue voltage signal
PLC compatible
Pressure monitoring
Machine diagnostics
Process control
Pneumatic systems
Low-pressure hydraulics
Pumps
Compressors
Process equipment
Industrial machinery
Pressure monitoring
Pressure alarms
PLC automation
Machine diagnostics
Preventive maintenance
Equipment protection
Process control
Industrial automation
Pressure regulation
| Specification | Details |
|---|---|
| Model | PT9543 |
| Order code | PT-025-SBG14-B-DVG/US//W |
| Pressure type | Relative |
| Measuring range | 0…25 bar |
| Equivalent | 0…362 psi |
| Output | 0…10 V |
| Process connection | G 1/4 |
| Supply | 16…36 V DC |
| Current consumption | <6 mA |
| Housing | Stainless steel |
| Media | Liquids/gases |
| Medium temperature | −25…90 °C |
| Pressure rating | High |
| Burst pressure | High |
| Repeatability | < ±0.1 % |
| Characteristics deviation | < ±1.0 % |
| Linearity | < ±0.25 % BFSL |
| Hysteresis | < ±0.2 % |
| Long-term stability | < ±0.1 % |
| Temperature coefficient | Low |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Application | Industrial |
