PT9542 is a compact industrial pressure transmitter with a 0–100 bar measuring range. It provides a 0–10 V analogue output for industrial control systems. The transmitter uses a stainless-steel housing for mechanical durability. Its G 1/4 process connection provides secure pressure-port installation. The compact design is suitable for pumps, process equipment and industrial machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PT9542 provides continuous relative pressure measurement in a 0–100 bar range. The voltage output can be connected to analogue input modules and controllers. Its robust construction supports demanding industrial environments. High repeatability and low hysteresis provide consistent measurement. The transmitter is suitable for pressure monitoring and automated control.
0…100 bar
0–10 V
Relative pressure
G 1/4 connection
16–36 V DC
Stainless steel
Compact housing
High repeatability
Low linearity deviation
Low hysteresis
Long-term stability
High shock resistance
High vibration resistance
IP67/IP69K class
Liquid/gas measurement
Pressure overload capability
PLC integration
Industrial automation
Pressure diagnostics
Pumps
Compressors
Industrial hydraulics
Process equipment
Pressure control
Pipelines
Tanks
Machine tools
Pressure alarms
Machine diagnostics
Equipment protection
Preventive maintenance
PLC automation
Industrial monitoring
Process automation
| Specification | Details |
|---|---|
| Model | PT9542 |
| Order code | PT-100-SBG14-B-DVG/US//W |
| Pressure type | Relative |
| Measuring range | 0…100 bar |
| Equivalent | 0…1450 psi |
| Output | 0…10 V |
| Process connection | G 1/4 |
| Supply | 16…36 V DC |
| Current consumption | <6 mA |
| Housing | Stainless steel |
| Media | Liquids/gases |
| Medium temperature | −25…90 °C |
| Pressure rating | High |
| Burst pressure | High |
| Repeatability | < ±0.1 % |
| Characteristics deviation | < ±1.0 % |
| Linearity | < ±0.25 % BFSL |
| Hysteresis | < ±0.2 % |
| Long-term stability | < ±0.1 % |
| Temperature coefficient | Low |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Application | Industrial |
