PT9541 is a compact 0–250 bar industrial pressure transmitter designed for dependable system-pressure measurement. It provides a 0–10 V analogue output for compatible automation equipment. Its stainless-steel housing offers strong mechanical resistance. The G 1/4 external thread provides secure installation. It is suitable for liquid and gas pressure monitoring in industrial machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PT9541 continuously measures relative pressure and converts it into a proportional voltage signal. The 250 bar range supports a broad range of industrial hydraulic applications. Its compact design enables installation in restricted machine areas. High repeatability supports stable measurement. The transmitter can be integrated with PLC analogue input systems.
0…250 bar
0–10 V output
Relative pressure
G 1/4 thread
16–36 V DC
Stainless steel
Compact body
High repeatability
Low linearity deviation
Low hysteresis
Long-term stability
Industrial design
High shock resistance
High vibration resistance
Liquid/gas compatible
Pressure overload capability
Analogue voltage signal
PLC compatible
Machine diagnostics
Preventive maintenance
Industrial hydraulics
Process systems
Pumps
Compressors
Pressure control
Industrial machinery
Pipeline monitoring
Tank monitoring
Machine diagnostics
Pressure alarms
Equipment protection
PLC automation
Process automation
Preventive maintenance
Industrial control
| Specification | Details |
|---|---|
| Model | PT9541 |
| Order code | PT-250-SBG14-B-DVG/US//W |
| Pressure type | Relative |
| Measuring range | 0…250 bar |
| Equivalent | 0…3625 psi |
| Output | 0…10 V |
| Process connection | G 1/4 |
| Supply | 16…36 V DC |
| Current consumption | <6 mA |
| Housing | Stainless steel |
| Media | Liquids/gases |
| Medium temperature | −25…90 °C |
| Pressure rating | 600 bar family |
| Burst capability | High |
| Repeatability | < ±0.1 % span |
| Characteristics deviation | < ±1.0 % span |
| Linearity | < ±0.25 % BFSL |
| Hysteresis | < ±0.2 % |
| Long-term stability | < ±0.1 % |
| Temperature coefficient | Low |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Application | Industrial |
