PT9540 is a compact industrial pressure transmitter designed for reliable system-pressure measurement. It provides a 0–400 bar measuring range and a 0–10 V analogue output. The stainless-steel housing offers strong resistance to shock and vibration. Its compact construction is suitable for restricted installation areas. The transmitter is designed for liquid and gaseous media in industrial applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PT9540 measures relative pressure and provides a proportional voltage output for industrial control systems. Its G 1/4 external thread allows secure process installation. The 16–36 V DC supply supports industrial control architectures. High repeatability and low linearity deviation contribute to stable pressure measurement. The product family is designed for more than 50 million pressure cycles.
The 0–400 bar range supports high-pressure process and hydraulic systems. The 0–10 V output can be connected to suitable analogue input modules. The transmitter is suitable for liquids and gases. Its robust construction supports continuous industrial operation. The device can be used for pressure control and machine protection.
0…400 bar range
0–10 V analogue output
Relative pressure
G 1/4 external thread
Stainless-steel housing
Compact design
16–36 V DC supply
High repeatability
Low linearity deviation
Low hysteresis
Long-term stability
IP67/IP69K class protection
High shock resistance
High vibration resistance
50-million-plus pressure cycles
Industrial application
Liquid and gas compatibility
Overload capability
Analogue voltage signal
PLC compatible
Industrial hydraulics
Process machinery
Pumps
Compressors
Industrial tanks
Pipelines
Pressure monitoring
Pressure control
Machine diagnostics
Equipment protection
Process automation
PLC systems
Preventive maintenance
Pressure alarms
Industrial automation
| Specification | Details |
|---|---|
| Model | PT9540 |
| Order code | PT-400-SBG14-B-DVG/US//W |
| Pressure type | Relative |
| Measuring range | 0…400 bar |
| Equivalent | 0…5800 psi / 0…40 MPa |
| Output | 0…10 V |
| Process connection | G 1/4 external |
| Supply voltage | 16…36 V DC |
| Current consumption | <6 mA |
| Housing | Stainless steel |
| Media | Liquids and gases |
| Medium temperature | −25…90 °C |
| Pressure rating | 600 bar |
| Burst pressure | 1600 bar |
| Repeatability | < ±0.1 % span |
| Characteristics deviation | < ±1.0 % span |
| Linearity | < ±0.25 % BFSL |
| Hysteresis | < ±0.2 % span |
| Long-term stability | < ±0.1 % span |
| Temperature coefficient | < ±0.1 % span/10 K |
| Protection | IP67/IP69K |
| Shock resistance | High |
| Vibration resistance | High |
| Pressure cycles | 50 million+ |
