PT5660 is a compact 600 bar pressure transmitter designed for demanding mobile and industrial pressure applications. It provides a 0–600 bar measuring range and a 4–20 mA analogue output. The transmitter uses a robust stainless-steel housing and G 1/4 external thread. It provides high resistance to shock and vibration and supports more than 60 million pressure cycles. Its compact design makes it suitable for restricted machine installations.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PT5660 provides continuous relative pressure measurement for high-pressure systems. Its 600 bar range is suitable for demanding hydraulic equipment. The 4–20 mA output integrates with PLCs and machine controllers. High repeatability and low characteristic deviation provide stable measurement. Its robust construction supports mobile machinery and industrial applications.
PT5660 is designed for long-term operation under repeated pressure loading. It supports a minimum pressure-cycle life of 60 million cycles at 1.2 times nominal pressure. Shock resistance reaches 500 g for 1 ms. Vibration resistance reaches 20 g across 10–2000 Hz. These characteristics make it suitable for harsh mobile-machine environments.
0–600 bar measuring range
4–20 mA output
Relative pressure
G 1/4 external thread
AMP Superseal connector
Stainless-steel construction
60-million pressure-cycle life
500 g shock resistance
20 g vibration resistance
IP67/IP69K
2 ms analogue response
High repeatability
Low hysteresis
Low linearity error
Long-term stability
Overload protection
Short-circuit protection
Compact body
Mobile-machine compatible
PLC integration
Hydraulic systems
Mobile machinery
Construction equipment
Agricultural equipment
Heavy machinery
Hydraulic power units
Pumps
Compressors
Industrial hydraulics
Pressure control
Machine diagnostics
Equipment protection
Preventive maintenance
Mobile automation
PLC systems
| Specification | Details |
|---|---|
| Model | PT5660 |
| Order code | PT-600-SEG14-A-ZVG/AM |
| Product type | Pressure transmitter |
| Pressure type | Relative |
| Measuring range | 0…600 bar |
| Equivalent | 0…8700 psi / 60 MPa |
| Output | 4–20 mA |
| Connector | AMP Superseal |
| Process connection | G 1/4 external |
| Supply | Model dependent |
| Max load | (Ub − 8 V)/21.5 mA |
| Repeatability | <±0.05% span |
| Characteristics deviation | <±0.8% span |
| Linearity | <±0.25% BFSL |
| Hysteresis | <±0.2% span |
| Long-term stability | <±0.1% span |
| Temperature coefficient | <±0.1% span/10 K central range |
| Response time | 2 ms |
| Ambient temperature | −40…100 °C |
| Storage temperature | −40…100 °C |
| Protection | IP67/IP69K |
| Shock resistance | 500 g / 1 ms |
| Vibration resistance | 20 g / 10–2000 Hz |
| Pressure cycles | 60 million |
| Housing | Stainless steel |
| Application | Mobile/industrial hydraulics |
