PP1/AP-3A is a cubic inductive proximity sensor for metal-target detection. The specified operating range or reference distance is 1.5 mm. The output is PNP. The supply is 10…30 VDC. The connection is Cable. Its mechanical construction follows the product configuration.
The sensing distance is 1.5 mm. Shielding is Shielded.
The specified value of 1.5 mm gives the reference distance or measurement envelope for the device.
The supply is 10…30 VDC. The output is PNP. The output is 200 mA. The output is NO.
The supply of 10…30 VDC defines the required operating voltage. The PNP output defines the switching or signal arrangement.
The connection is Cable. Protection is rated IP67.
The Cable connection provides the stated physical interface. Protection is rated IP67.
The sensor type is Cubic inductive proximity sensor. The dimensions is 5 x 5 x 25 mm. The sensing distance is 1.5 mm. Shielding is Shielded. The output is PNP. The output is NO. The supply is 10…30 VDC. The output is 200 mA. Protection is rated IP67. The status is LED.
PP1/AP-3A combines the cubic inductive proximity sensor characteristics given in the product specification. The sensor type is Cubic inductive proximity sensor. The sensing distance is 1.5 mm. The output is PNP. The supply is 10…30 VDC. The connection is Cable. Protection is rated IP67. These technical values describe the sensing, electrical and mechanical properties of PP1/AP-3A.
| Specification | Value |
|---|---|
| Model | PP1/AP-3A |
| Sensor type | Cubic inductive proximity sensor |
| Dimensions | 5 x 5 x 25 mm |
| Sensing distance | 1.5 mm |
| Shielding | Shielded |
| Output | PNP |
| Logic | NO |
| Supply | 10…30 VDC |
| Output current | 200 mA |
| Protection | IP67 |
| Status | LED |
| Connection | Cable |
