The IFM PM1118 is a low-pressure flush sensor designed for accurate measurement in hygienic process applications. Its factory range is 0...160 inHâ‚‚O, providing sensitivity for low-pressure monitoring. It supports scalable 4...20 mA output and IO-Link digital communication. The flush sensing design supports clean process installation and easy integration. PM1118 is suitable for automated equipment requiring stable low-pressure measurement and digital diagnostics.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PM1118 is designed for applications involving low pressure and relatively small pressure variations. Its factory range is 0...160 inHâ‚‚O with an extended full measurement range. IO-Link provides additional measurement flexibility and fine digital resolution. The sensor is suitable for monitoring process pressure continuously. Its overload rating provides protection against temporary pressure excursions.
The flush sensing surface supports hygienic process integration. Stainless-steel construction is suitable for demanding industrial environments. The sensor design helps minimise contamination points in the process connection. It can be used in production systems that require frequent cleaning. The compact construction supports installation in process machinery.
The sensor combines scalable analogue output with IO-Link communication. Analogue output enables direct integration with standard control equipment. IO-Link provides parameterisation, diagnostics and digital process values. This allows better visibility of pressure and sensor status. The combination makes PM1118 suitable for modern automated process systems.
0...160 inHâ‚‚O factory range
Extended measurement range
Flush sensing surface
4...20 mA scalable output
IO-Link communication
Fine digital resolution
Stainless-steel construction
Hygienic process design
Digital diagnostics
Parameterisation
Continuous monitoring
PLC integration
Low-pressure process control
Hygienic production systems
Food processing
Beverage equipment
Filling machinery
Process piping
Pump monitoring
Liquid handling
PLC automation
Machine monitoring
Process instrumentation
Industrial automation
| Specification | PM1118 |
|---|---|
| Product type | Flush pressure sensor |
| Model | PM1118 |
| Factory range | 0...160 inHâ‚‚O |
| Full range | -20...160 inHâ‚‚O |
| IO-Link range | -28...169 inHâ‚‚O |
| Resolution | 0.04 inHâ‚‚O |
| Overload pressure | 116 psi |
| Burst pressure | 435 psi |
| Output | 4...20 mA |
| Communication | IO-Link |
| Signal | Scalable analogue |
| Pressure type | Relative |
| Measuring principle | Electronic |
| Sensing design | Flush |
| Housing | Stainless steel |
| Process use | Hygienic |
| Installation | Process connection |
| Parameterisation | IO-Link |
| Diagnostics | Digital |
| Process data | Available |
| PLC connection | Analogue/IO-Link |
| Mounting | Process mounted |
| Environment | Industrial |
| Primary function | Low-pressure measurement |
| Automation | Supported |
