PD1/AN-3F is an inductive proximity sensor for metal-target detection. The specified operating range or reference distance is 1.5 mm. The output is NPN. The supply is 10…30 VDC. The housing is M5.
The sensing distance is 1.5 mm. Shielding is Shielded.
The specified value of 1.5 mm gives the reference distance or measurement envelope for the device.
The supply is 10…30 VDC. The output is NPN. The output is NO. The output is 100 mA max. The switching frequency is 3000 Hz max. The power-on delay is 10 ms.
The supply of 10…30 VDC defines the required operating voltage. The NPN output defines the switching or signal arrangement. The switching frequency is 3000 Hz max.
The housing is M5. Protection is rated IP67. The operating temperature range is -25…+70 °C.
The M5 housing provides the specified mechanical format. Protection is rated IP67.
The sensor type is Inductive proximity sensor. The housing is M5. The sensing distance is 1.5 mm. Shielding is Shielded. The output is NPN. The output is NO. The supply is 10…30 VDC. The output is 100 mA max. The switching frequency is 3000 Hz max. The power-on delay is 10 ms.
PD1/AN-3F combines the inductive proximity sensor characteristics given in the product specification. The sensor type is Inductive proximity sensor. The sensing distance is 1.5 mm. The output is NPN. The supply is 10…30 VDC. The housing is M5. Protection is rated IP67. These technical values describe the sensing, electrical and mechanical properties of PD1/AN-3F.
| Specification | Value |
|---|---|
| Model | PD1/AN-3F |
| Sensor type | Inductive proximity sensor |
| Housing | M5 |
| Sensing distance | 1.5 mm |
| Shielding | Shielded |
| Output | NPN |
| Output logic | NO |
| Supply | 10…30 VDC |
| Output current | 100 mA max. |
| Switching frequency | 3000 Hz max. |
| Power-on delay | 10 ms |
| Protection | IP67 |
| Temperature | -25…+70 °C |
| Status | LED |
