The IFM IB0016 is an inductive sensor with a 34 mm diameter and 98 mm length, designed for non-flush installation with a 20 mm sensing range. It provides selectable normally-open or normally-closed operation and supports AC/DC applications. The sensor uses a two-wire connection, has IP65 protection, and supports switching frequencies of 25 Hz AC and 50 Hz DC, making it suitable for industrial automation and machine monitoring.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IB0016 is an inductive sensor designed for reliable metallic target detection in industrial applications. IFM catalog information specifies a 34 mm diameter, 98 mm length, and 20 mm sensing range with non-flush installation. Its selectable normally-open/normally-closed operation and AC/DC capability provide flexibility for different machine-control requirements.
The IB0016 is suitable for industrial sensing tasks where metallic targets must be detected reliably during machine operation. Its 20 mm sensing range provides non-contact detection, while the two-wire design simplifies electrical integration. IP65 protection and an operating temperature range of -25 to 80 °C support use in suitable industrial environments.
The IB0016 provides flexible inductive detection with selectable switching behavior and AC/DC operation. Its 20 mm sensing range and non-flush mounting make it suitable for applications where increased detection distance is required. The robust industrial design supports machine automation, position monitoring, and metallic object detection.
20 mm sensing range
Non-flush mounting
34 mm diameter housing
98 mm housing length
Normally-open/normally-closed selectable
AC/DC operation
Two-wire technology
IP65 protection
25 Hz AC switching frequency
50 Hz DC switching frequency
Machine position detection
Metal object detection
Industrial automation
Production machinery
Machine monitoring
Conveyor systems
Material handling
Assembly equipment
Presence detection
Factory automation
| Specification | Details |
|---|---|
| Product Code | IB0016 |
| Model | IBE2020-FBOA |
| Product Type | Inductive sensor |
| Sensing Range | 20 mm |
| Electrical Design | AC/DC |
| Output Function | Normally open / normally closed selectable |
| Operating Voltage | AC/DC / model-specific |
| Current Consumption | Model-specific / refer to IFM datasheet |
| Housing Material | Model-specific / refer to IFM datasheet |
| Housing Design | Ø34 mm / L=98 mm |
| Connection | Terminal connection |
| Connector | Terminal connection |
| Protection Rating | IP65 |
| Protection Class | Model-specific / refer to IFM datasheet |
| Switching Frequency | 25 Hz AC / 50 Hz DC |
| Response Time | Model-specific / refer to IFM datasheet |
| Ambient Temperature | -25...80 °C |
| Installation | Non-flush |
| Mounting | Model-specific / refer to IFM datasheet |
| LED Indicator | Model-specific / refer to IFM datasheet |
| Short-Circuit Protection | Model-specific / refer to IFM datasheet |
| Overload Protection | Model-specific / refer to IFM datasheet |
| Reverse Polarity Protection | Model-specific / refer to IFM datasheet |
| Weight | Model-specific / refer to IFM datasheet |
| Additional Information | Two-wire inductive sensor for AC/DC applications |
