The IFM IGR203 is an inductive sensor with an M18 x 1 housing and 35 mm length, designed for flush-mountable metallic target detection. The specified version provides a 6 mm sensing range, PNP/NPN operation, a 0.3 m PVC cable, M12 connection, IP65/IP66/IP67/IP68/IP69K protection, and a -40 to 85 °C ambient temperature range.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IGR203 is designed for reliable inductive detection in demanding industrial applications. IFM catalog information specifies an M18 x 1 housing with 35 mm length and a 6 mm flush-mountable sensing range. The specified version supports PNP/NPN operation and combines a short PVC cable with M12 connection for practical machine integration.
The IGR203 is suitable for industrial environments requiring reliable metallic target detection across a wide range of operating conditions. Its protection ratings extend from IP65 through IP69K, supporting demanding installations when correctly integrated. The -40 to 85 °C operating range and 50 Hz switching frequency make it suitable for a variety of machine automation tasks.
The IGR203 offers flexible PNP/NPN operation, a compact M18 x 1 housing, and broad environmental protection. Its 6 mm sensing range supports non-contact detection while the IP65/IP66/IP67/IP68/IP69K ratings provide strong protection for suitable industrial installations. It is suitable for machine position, component, and presence detection.
M18 x 1 threaded housing
35 mm housing length
6 mm sensing range
Flush-mountable design
PNP/NPN operation
0.3 m PVC cable
M12 connection
IP65/IP66/IP67/IP68/IP69K protection
-40...85 °C operating range
50 Hz switching frequency
Machine position detection
Metal component sensing
Industrial machinery
Production equipment
Conveyor systems
Assembly automation
Material handling
Object presence detection
Machine monitoring
Factory automation
| Specification | Details |
|---|---|
| Product Code | IGR203 |
| Model | IGB2006BARKG/AM/SC/0,3M/US/2LE |
| Product Type | Inductive sensor |
| Sensing Range | 6 mm |
| Electrical Design | PNP/NPN |
| Output Function | Normally open |
| Operating Voltage | Model-specific / refer to IFM datasheet |
| Current Consumption | Model-specific / refer to IFM datasheet |
| Housing Material | Model-specific / refer to IFM datasheet |
| Housing Design | M18 x 1 / L=35 mm |
| Connection | 0.3 m PVC cable / M12 |
| Connector | M12 |
| Protection Rating | IP65 / IP66 / IP67 / IP68 / IP69K |
| Protection Class | Model-specific / refer to IFM datasheet |
| Switching Frequency | 50 Hz |
| Response Time | Model-specific / refer to IFM datasheet |
| Ambient Temperature | -40...85 °C |
| Installation | Flush mountable |
| Mounting | M18 x 1 threaded |
| LED Indicator | Model-specific / refer to IFM datasheet |
| Short-Circuit Protection | Model-specific / refer to IFM datasheet |
| Overload Protection | Model-specific / refer to IFM datasheet |
| Reverse Polarity Protection | Model-specific / refer to IFM datasheet |
| Weight | Model-specific / refer to IFM datasheet |
| Additional Information | Multiple IP protection ratings for demanding installations |
