The IFM IFG3005-BPKG/5M RT Inductive Sensor provides reliable 5 mm metal detection with PNP normally open output, 1000 Hz switching frequency, and a 5 m PVC cable for industrial automation applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM IF5822 Inductive Sensor is designed for reliable metal detection in Industrial Equipment & Supplies in UAE and factory automation environments. It provides non-contact detection for machines, conveyors, production equipment, and automated handling systems.
With a 5 mm sensing range, the sensor offers dependable detection of metallic targets while its cylindrical design provides flexible installation. The PNP normally open output allows simple integration with PLCs and industrial automation controllers.
The sensor operates from 10–36 V DC and supports a switching frequency of up to 1000 Hz. Its 5 m PVC cable provides extended connection distance, while IP67 protection supports reliable operation in industrial environments.
• 5 mm sensing range
• PNP normally open output
• 10–36 V DC operation
• 1000 Hz switching frequency
• Ø11 mm cylindrical housing
• Non-flush mountable
• 5 m PVC cable
• IP67 protection
• Short-circuit protection
• Overload protection
• Red LED switching indication
Ideal for factory automation, conveyor systems, machine monitoring, material handling systems, assembly machinery, packaging equipment, position detection, and automated production lines.
| Specification | Details |
|---|---|
| Product Model | IFG3005-BPKG/5M RT |
| Part Number | IF5822 |
| Product Type | Inductive Proximity Sensor |
| Sensing Range | 5 mm |
| Electrical Design | PNP |
| Output Function | Normally Open |
| Operating Voltage | 10–36 V DC |
| Current Consumption | 15 mA at 24 V |
| Permanent Current Rating | 250 mA |
| Switching Frequency | 1000 Hz |
| Operating Distance | 0–4.05 mm |
| Mounting | Non-flush |
| Housing Type | Cylindrical |
| Dimensions | Ø11 mm / L = 54 mm |
| Housing Material | PBT |
| Cable Length | 5 m |
| Cable Material | PVC |
| Protection Rating | IP67 |
| Ambient Temperature | -25°C to +80°C |
| Status Indicator | Red LED |
| Weight | 191.5 g |
