IFM IF5542 inductive proximity sensor with a compact M12 × 1 metal housing, 2 mm sensing range, PNP normally closed output, high 1.5 kHz switching frequency, and IP67 protection for reliable industrial automation and factory applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM IF5542 inductive sensor (IFB3002-APKG/US-104) is a compact proximity sensor designed for reliable non-contact detection of metallic objects in industrial automation and factory applications. Its particularly short housing makes it suitable for installations where space is restricted, while its robust metal construction supports dependable operation in demanding industrial environments.
With a 2 mm sensing range, PNP normally closed output, and switching frequency of up to 1.5 kHz, the IF5542 provides fast and consistent object detection for automated machinery, positioning systems, production lines, and industrial equipment. The sensor operates from 10–30 V DC and includes reverse-polarity, short-circuit, and overload protection.
IFM IF5542 inductive proximity sensor
Model: IFB3002-APKG/US-104
2 mm nominal sensing range
PNP normally closed output
10–30 V DC operating voltage
Up to 1.5 kHz switching frequency
100 mA continuous switching current
M12 × 1 threaded housing
Flush-mountable design
M12 connector connection
Gold-plated connector contacts
Robust metal housing
IP67 protection rating
Yellow LED switching indication
Reverse-polarity protection
Short-circuit protection
Overload protection
Non-contact metallic object detection
Suitable for industrial automation applications
Suitable for factory automation and machinery
The IF5542 features a particularly short housing for applications with limited installation space. Its M12 × 1 threaded design enables convenient installation while maintaining a compact footprint for automated machinery and equipment.
This inductive sensor detects metallic objects without physical contact, making it suitable for position monitoring, presence detection, counting, and machine automation applications. Its 2 mm sensing range provides dependable detection in compact sensing arrangements.
With a switching frequency of up to 1.5 kHz, the IF5542 is designed for high-speed sensing requirements. This makes it suitable for production machinery, conveyor systems, automated handling equipment, and other high-cycle industrial processes.
The sensor has an IP67 protection rating and a robust metal housing designed for demanding industrial environments. It also incorporates electrical protection features including reverse-polarity, short-circuit, and overload protection for dependable operation.
The IF5542 is suitable for:
The IF5542 is a practical choice for businesses looking for an Industrial Sensors Supplier UAE for compact, high-speed proximity sensing. It can be integrated into Industrial Automation Components UAE and factory automation systems where reliable metallic object detection and space-efficient installation are required.
| Specification | Details |
| Product Model | IF5542 |
| Model / Type | IFB3002-APKG/US-104 |
| Product Type | Inductive Sensor |
| Sensor Type | Inductive Proximity Sensor |
| Application | Industrial applications / Factory automation |
| Electrical Design | PNP, normally closed |
| Sensing Range | 2 mm |
| Real Sensing Range (Sr) | 2 ± 10% |
| Operating Range | 0–1.62 mm |
| Operating Voltage | 10–30 V DC |
| Switching Frequency | 1.5 kHz |
| Continuous Current Rating | 100 mA |
| Housing Thread | M12 × 1 |
| Housing Length | 45 mm |
| Mounting | Flush mountable |
| Connection | M12 connector |
