The IFM IER201 IEK3002BANKG/AM/SC/US-104 inductive full-metal sensor is a robust M8 × 1 proximity sensor designed for reliable non-contact detection of metallic objects in demanding industrial environments. It features a 2 mm sensing range, NPN normally-open output, 10–30 V DC operation, 100 Hz switching frequency, increased sensing range and full-metal stainless-steel anti-spatter construction. Its robust metal sensing face, gold-plated contacts and protection against dust, water and harsh operating conditions make it suitable for welding, metalworking, machine tools and industrial automation applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM IER201 IEK3002BANKG/AM/SC/US-104 is an inductive full-metal sensor engineered for reliable non-contact detection of metallic objects in industrial machinery, machine tools, metalworking equipment and factory automation systems.
The sensor uses inductive proximity sensing technology, allowing metallic targets to be detected without physical contact. This makes it suitable for repeated detection of machine components, workpieces, fixtures and moving metallic parts while avoiding mechanical wear associated with conventional contact switches.
The IER201 provides a 2 mm sensing range, with a real sensing range of 2 ± 10% mm and an operating distance of 0–1.62 mm. Its increased sensing range provides additional detection capability while maintaining a compact M8 × 1 sensor design.
The sensor uses a DC NPN normally-open output and operates from a 10–30 V DC supply. It supports a 100 mA permanent switching current and a 100 Hz switching frequency, making it suitable for repetitive detection tasks in industrial machinery and automated production systems.
The IER201 features a full-metal stainless-steel housing and sensing face with anti-spatter construction. The housing and sensing face are made from stainless steel 1.4404 / 316L, providing a robust sensing solution for demanding industrial applications and welding environments.
The sensor has an M8 × 1 threaded housing with a 60 mm overall length and is designed for flush mounting. It uses an M12 connector with gold-plated contacts and provides four yellow LEDs for switching-status indication.
IFM IER201 inductive full-metal sensor
Model: IEK3002BANKG/AM/SC/US-104
Inductive non-contact metal detection
2 mm sensing range
Real sensing range: 2 ± 10% mm
Operating distance: 0–1.62 mm
Increased sensing range
DC NPN electrical design
Normally-open output
10–30 V DC operating voltage
100 mA permanent switching current
100 Hz switching frequency
Full-metal housing
Stainless-steel 1.4404 / 316L construction
Anti-spatter housing
Anti-spatter sensing face
Suitable for welding applications
M8 × 1 threaded housing
60 mm overall length
Flush-mountable construction
M12 connector
Gold-plated connector contacts
Four yellow LED switching-status indicators
IP67 protection
IP68 protection
50 bar pressure rating at sensing face
5 MPa pressure rating at sensing face
Reverse-polarity protection
Short-circuit protection
Overload protection
Suitable for demanding industrial environments
Suitable for machine tools and metalworking
Suitable for industrial automation and factory automation
The IER201 operates using an inductive sensing principle to detect metallic objects without direct physical contact.
When a suitable metallic target enters the detection zone, the sensor switches its NPN normally-open output. The switching signal can be connected to a PLC, industrial controller or compatible automation system for machine sequencing, position monitoring, object detection and process control.
Its full-metal construction provides a robust solution for applications where the sensor may be exposed to mechanical stress, metal particles, welding residue or other demanding industrial conditions.
The IER201 provides a 2 mm nominal sensing range with an increased sensing range.
Its real sensing range is specified as 2 ± 10% mm, with an operating distance of 0–1.62 mm. The correction factor depends on the target material and should be considered when designing the sensing application.
Steel: 1
Stainless steel: 0.7
Brass: 0.7
Aluminium: 0.6
Copper: 0.5
These correction factors help determine the practical sensing distance for different metallic target materials.
The IER201 uses a DC NPN normally-open output, making it suitable for compatible industrial control systems.
When a metallic target is detected within the sensing zone, the sensor changes its output state and provides a switching signal to the connected control system.
Its 100 mA permanent switching current and 100 Hz switching frequency support repeated detection in automated machinery and production equipment.
A major advantage of the IER201 is its full-metal stainless-steel construction.
The housing and sensing face are manufactured from stainless steel 1.4404 / 316L, with anti-spatter construction. This makes the sensor particularly suitable for applications involving welding and metalworking.
The robust sensing face is designed for heavy-duty industrial applications, while the anti-spatter construction helps support reliable sensor operation in welding environments.
The IER201 uses an M8 × 1 threaded housing with a 60 mm overall length.
Its threaded construction allows secure installation into compatible machine structures, while the flush-mountable design provides a clean and practical installation arrangement.
The IER201 provides a documented 50 bar / 5 MPa pressure rating at the sensing face, making it suitable for demanding industrial applications where the sensing face may be exposed to elevated pressure.
The sensor uses an M12 connector with gold-plated contacts.
Four yellow LEDs provide switching-status indication, helping technicians identify the sensor's operating condition during installation, commissioning and maintenance.
Welding Machinery
The IER201 is suitable for welding applications because of its full-metal anti-spatter construction.
Machine Tool Applications
The sensor can provide reliable proximity feedback for machine tools requiring detection of metallic components.
Metalworking Equipment
Its stainless-steel full-metal construction makes it suitable for demanding metalworking machinery.
Machine Position Detection
The sensor can detect the position of metallic machine components, fixtures, slides and moving mechanisms.
Metal Component Detection
It can detect the presence or absence of metallic workpieces and components during manufacturing processes.
Conveyor Automation
The IER201 can detect metallic workpieces moving through automated conveyor systems.
Production Machinery
It can provide switching feedback for automated machine sequences and production operations.
Factory Automation
The sensor can be integrated into factory automation systems requiring dependable non-contact metal detection.
The IER201 is designed for reliable operation in demanding industrial environments.
Its 2 mm sensing range, increased sensing capability and 100 Hz switching frequency support dependable detection during repetitive machine operations. Its full-metal anti-spatter construction makes it particularly suitable for harsh environments and welding applications.
The sensor provides IP67 and IP68 protection, helping protect the sensor against dust and water ingress under the specified operating conditions. The documented ambient temperature range is 0 °C to +85 °C.
The IER201 operates from a 10–30 V DC supply and has a current consumption of less than 10 mA according to the current IFM product documentation.
The sensor incorporates reverse-polarity protection, short-circuit protection and overload protection, supporting reliable integration into industrial electrical and automation systems.
The maximum switching voltage drop is 2.5 V, while the permanent switching current is 100 mA. The switching frequency is 100 Hz.
The IER201 can be incorporated into Industrial Automation UAE systems requiring robust non-contact metal detection.
It can operate alongside Industrial Automation Components UAE, including PLCs, control panels, actuators, drives, switches and other industrial sensors.
For Industrial Automation Suppliers UAE, the IER201 provides a dependable full-metal sensing solution for machine builders, system integrators, welding equipment manufacturers and manufacturing facilities.
For businesses looking for an Industrial Sensors Supplier UAE, Proximity Sensors Supplier UAE or Sensor Supplier UAE, the IER201 is particularly suitable where stainless-steel construction, anti-spatter protection and reliable metal detection are important requirements.
Full-metal stainless-steel construction
Anti-spatter housing
Anti-spatter sensing face
Designed for welding applications
2 mm sensing range
Increased sensing range
0–1.62 mm operating distance
NPN normally-open output
10–30 V DC operation
100 mA permanent switching current
100 Hz switching frequency
M8 × 1 threaded design
60 mm overall length
Flush-mountable installation
Gold-plated M12 connector contacts
Four yellow switching-status LEDs
IP67 protection
IP68 protection
50 bar pressure rating at sensing face
5 MPa pressure rating at sensing face
Reverse-polarity protection
Short-circuit protection
Overload protection
Stainless-steel 1.4404 / 316L materials
Suitable for metalworking
Suitable for welding equipment
Suitable for machine tools
Suitable for factory automation
The IFM IER201 IEK3002BANKG/AM/SC/US-104 is a robust inductive full-metal sensor designed for reliable non-contact metal detection in demanding industrial applications. Its 2 mm sensing range, NPN normally-open output, M8 × 1 construction, stainless-steel anti-spatter housing, increased sensing range and IP67/IP68 protection make it suitable for welding machinery, metalworking equipment, machine tools and factory automation.
It is suitable for businesses seeking Industrial Sensors Supplier UAE, Proximity Sensors Supplier UAE, Sensor Supplier UAE, Industrial Automation Supplier in UAE, Industrial Automation Components UAE and Industrial Automation Equipment UAE.
| Specification | Details |
|---|---|
| Product Code | IER201 |
| Manufacturer | IFM |
| Model / Part Number | IEK3002BANKG/AM/SC/US-104 |
| Product Type | Inductive Full-Metal Sensor |
| Sensor Type | Inductive Proximity Sensor |
| Electrical Design | DC NPN |
| Output Function | Normally Open |
| Operating Voltage | 10–30 V DC |
| Current Consumption | < 10 mA |
| Protection Class | III |
| Reverse Polarity Protection | Yes |
| Short-Circuit Protection | Yes |
| Overload Protection | Yes |
| Maximum Voltage Drop | 2.5 V |
| Permanent Switching Current | 100 mA |
| Switching Frequency | 100 Hz |
| Sensing Range | 2 mm |
| Real Sensing Range (Sr) | 2 ± 10% mm |
| Operating Distance | 0–1.62 mm |
| Increased Sensing Range | Yes |
| Hysteresis | 1–20% of Sr |
| Correction Factor – Steel | 1 |
| Correction Factor – Stainless Steel | 0.7 |
| Correction Factor – Brass | 0.7 |
| Correction Factor – Aluminium | 0.6 |
| Correction Factor – Copper | 0.5 |
| Housing Type | Threaded |
| Thread | M8 × 1 |
| Overall Length | 60 mm |
| Mounting | Flush mountable |
| Full-Metal Housing | Yes |
| Housing Material | Stainless steel 1.4404 / 316L, anti-spatter |
| Sensing Face Material | Stainless steel 1.4404 / 316L, anti-spatter |
| Lock Nut Material | Stainless steel 1.4404 / 316L, anti-spatter |
| Tightening Torque | < 5 Nm |
| Connection | 1 × M12 connector |
| Connector Contacts | Gold-plated |
| LED Indication | 4 × yellow LED |
| Switching Status Indication | Yes |
| Pressure Rating | 50 bar / 5 MPa at sensing face |
| Application | Use in welding applications |
| Protection Rating | IP67 / IP68 |
| Ambient Temperature | 0 °C to +85 °C |
| Impact Resistance | 1 J |
| EMC Standard | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, EN 55011 Class B |
| UL Approval | Yes |
| UL File Number | E174191 |
| Weight | Approx. 21.1 g |
| MTTF | Approx. 1389 years |
| Accessories Included |
