The IE5453 IEB3002BBPKG/V4A/ZH inductive sensor by IFM is designed for reliable non-contact detection of metallic objects in industrial automation, machinery and factory applications. With a 2 mm sensing range, PNP normally-open output, 10–30 V DC operation, 1500 Hz switching frequency, stainless-steel housing and IP67 protection, it provides dependable sensing performance in compact industrial installations.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IE5453 IEB3002BBPKG/V4A/ZH inductive sensor by IFM is engineered for reliable non-contact detection of metallic objects in industrial automation, machine control and factory production applications. Its particularly short housing makes it suitable for installations where mounting space is restricted while reliable metal detection and high-speed switching performance are required.
The sensor uses inductive proximity sensing technology to detect metallic objects without physical contact. This makes the IE5453 suitable for repeated detection of machine components, workpieces, moving parts and metallic objects in automated processes.
The IE5453 provides a 2 mm sensing range, with a real sensing range of 2 ± 10% mm and an operating distance of 0–1.62 mm. This sensing capability supports reliable detection of suitable metallic targets in machinery and automated production systems.
The sensor features a PNP electrical design with a normally-open output. It operates on a 10–30 V DC supply and supports a high 1500 Hz switching frequency, making it suitable for fast and repetitive detection tasks in industrial machinery.
The IE5453 features a particularly short M8 × 1 threaded housing with an overall length of only 30 mm. Its flush-mountable construction makes it practical for compact machine structures, fixtures and automated equipment where installation space is limited.
The sensor uses a robust stainless-steel housing made from 1.4404 / 316L material, while the active face is manufactured from LCP. This construction makes the sensor suitable for demanding industrial environments.
The IE5453 provides an IP67 protection rating, helping protect the sensor against dust and water ingress under specified operating conditions. It is designed for an ambient temperature range of 10 °C to +85 °C.
The sensor is supplied with a 2 m PUR cable with 3 × 0.14 mm² conductors. A yellow LED provides clear switching-status indication, helping technicians identify the operating state during installation, commissioning and maintenance.
For businesses seeking Industrial Automation UAE, Industrial Sensors Supplier UAE, Proximity Sensors Supplier UAE and Automation Products Supplier UAE, the IE5453 provides a compact and dependable inductive sensing solution for industrial machinery and factory automation.
IFM IE5453 inductive proximity sensor
Model: IEB3002BBPKG/V4A/ZH
2 mm sensing range
Real sensing range: 2 ± 10%
Operating distance: 0–1.62 mm
PNP electrical design
Normally-open output
10–30 V DC operating voltage
1500 Hz switching frequency
100 mA permanent switching current
M8 × 1 threaded housing
30 mm overall length
Flush-mountable construction
Stainless-steel 1.4404 / 316L housing
LCP active face
2 m PUR cable
3 × 0.14 mm² cable conductors
IP67 protection rating
10 °C to +85 °C ambient temperature
Reverse-polarity protection
Short-circuit protection
Overload protection
Yellow LED switching-status indication
Particularly short housing for restricted spaces
The IE5453 operates using an inductive sensing principle, detecting metallic objects without direct physical contact. When a suitable metallic target enters the sensing zone, the sensor changes its normally-open output state.
Its PNP electrical design allows the sensor to be integrated into compatible PLCs, industrial controllers and automation systems.
The M8 × 1 threaded construction and 30 mm short housing make the IE5453 particularly useful in machinery where conventional sensors with longer housings may be difficult to install. Its flush-mountable construction allows practical integration into suitable machine structures.
The IE5453 provides a 2 mm sensing range, with a real sensing range of 2 ± 10% mm and an operating distance of 0–1.62 mm.
Its 1500 Hz switching frequency supports fast and repetitive detection operations in automated machinery and production equipment. This high switching frequency is particularly useful where metallic targets need to be detected repeatedly at higher operating speeds.
The correction factors for different metallic target materials are:
Steel: 1
Stainless steel: 0.7
Brass: 0.5
Aluminium: 0.4
Copper: 0.3
The sensor has a hysteresis of 1–15% of Sr and switch-point drift of -10 to +10% of Sr.
The IE5453 uses a PNP normally-open output, making it suitable for compatible industrial control systems.
When the sensor detects a suitable metallic target, its switching output changes state and provides a detection signal to the connected PLC or automation controller.
The sensor supports a permanent switching current of 100 mA and has a maximum switching-output voltage drop of 2.5 V.
This makes the sensor suitable for:
Machine position detection
Metal component detection
Object presence monitoring
Conveyor monitoring
Automated counting
Production-line control
Assembly machinery
Machine status feedback
The IE5453 features a particularly short M8 × 1 housing with an overall length of 30 mm.
This compact construction is useful for machine structures, fixtures and automation equipment where longer sensors may be difficult to install.
The flush-mountable design provides practical integration into suitable machine structures while maintaining reliable proximity detection.
For Industrial automation companies UAE, the short housing can provide additional flexibility when designing compact automated machinery and factory production systems.
The IE5453 uses a stainless-steel housing made from 1.4404 / 316L material and an LCP active face. This robust construction is suitable for industrial environments where durable sensor housing is required.
The stainless-steel housing also supports applications where a compact metal sensor construction is preferred.
The IE5453 can be incorporated into Industrial automation solutions in UAE across manufacturing, engineering, machine building, packaging, material handling and factory production environments.
Machine Position Detection
The sensor can detect the position of metallic moving parts, slides, machine components and mechanical fixtures.
Metal Component Detection
It can detect the presence or absence of metal workpieces and components during manufacturing and assembly processes.
Conveyor Automation
The IE5453 can monitor metallic objects moving along conveyor systems and provide switching feedback to compatible control equipment.
Automated Counting
The sensor can detect individual metallic objects passing a sensing point for automated counting and production monitoring.
Assembly Machinery
The IE5453 can confirm whether a metallic component is present at a particular stage of an automated assembly process.
Material Handling Equipment
The sensor can provide proximity feedback in automated material handling and transfer systems.
Production Machinery
It can support machine-control functions where reliable non-contact detection of metallic components is required.
The IE5453 can operate as part of larger Industrial automation systems in UAE, providing proximity feedback to compatible PLCs and industrial controllers.
It can be incorporated alongside other Industrial Automation Components UAE, such as PLCs, control panels, actuators, switches, drives and other industrial sensors.
For Industrial Automation Suppliers UAE, machine builders and system integrators, the IE5453 offers a compact inductive sensing component for machine automation and factory production applications.
Its PNP normally-open output makes it suitable for compatible control architectures where this switching configuration is required.
The IE5453 provides an IP67 protection rating, helping protect the sensor against dust and water ingress under specified operating conditions.
The specified ambient temperature range of 10 °C to +85 °C provides flexibility for a range of industrial machinery and factory environments.
The sensor also incorporates reverse-polarity, short-circuit and overload protection, supporting dependable electrical operation when installed according to the manufacturer's requirements.
The IE5453 is supplied with a 2 m PUR cable with 3 × 0.14 mm² conductors.
The cable provides a practical connection solution for industrial machine installations and factory automation equipment.
A yellow LED switching-status indicator provides visual feedback during installation, commissioning and maintenance, helping technicians identify whether the sensor is responding to a detected target.
2 mm sensing range
Reliable non-contact metal detection
PNP normally-open output
10–30 V DC operation
1500 Hz switching frequency
Flush-mountable M8 × 1 construction
30 mm particularly short housing
Stainless-steel 1.4404 / 316L housing
LCP active face
2 m PUR connection cable
IP67 protection
10 °C to +85 °C operating temperature
Reverse-polarity protection
Short-circuit protection
Overload protection
Yellow switching-status LED
Suitable for restricted installation spaces
Suitable for high-speed repetitive detection
The IE5453 IEB3002BBPKG/V4A/ZH is a compact and robust IFM inductive proximity sensor designed for reliable non-contact metal detection in industrial automation. Its 2 mm sensing range, PNP normally-open output, 1500 Hz switching frequency, short M8 × 1 housing, stainless-steel construction, 2 m PUR cable and IP67 protection make it suitable for machinery, conveyors, assembly systems, production equipment and factory automation applications.
For businesses searching for Industrial Sensors Supplier UAE, Proximity Sensors Supplier UAE, Sensor Supplier UAE, Industrial Automation Equipment UAE and Factory Automation Components, the IE5453 provides a practical solution for reliable metal detection in compact industrial installations.
| Feature | Specification |
|---|---|
| Product Code | IE5453 |
| Manufacturer | IFM |
| Model / Part Number | IEB3002BBPKG/V4A/ZH |
| Product Type | Inductive Sensor |
| Sensor Type | Inductive / Proximity Sensor |
| Electrical Design | PNP |
| Output Function | Normally Open |
| Operating Voltage | 10–30 V DC |
| Current Consumption | < 15 mA |
| Protection Class | III |
| Reverse Polarity Protection | Yes |
| Sensing Range | 2 mm |
| Real Sensing Range (Sr) | 2 ± 10% mm |
| Operating Distance | 0–1.62 mm |
| Housing Type | Threaded |
| Thread | M8 × 1 |
| Overall Length | 30 mm |
| Mounting | Flush mountable |
| Housing Material | Stainless steel 1.4404 / 316L |
| Active Face Material | LCP |
| Switching Frequency | 1500 Hz |
| Permanent Switching Current | 100 mA |
| Maximum Voltage Drop | 2.5 V |
| Hysteresis | 1–15% of Sr |
| Switch-Point Drift | -10 to +10% of Sr |
| Correction Factor – Steel | 1 |
| Correction Factor – Stainless Steel | 0.7 |
| Correction Factor – Brass | 0.5 |
| Correction Factor – Aluminium | 0.4 |
| Correction Factor – Copper | 0.3 |
| Short-Circuit Protection | Yes |
| Short-Circuit Protection Type | Pulsed |
| Overload Protection | Yes |
| Connection | 2 m PUR cable |
| Cable Conductors | 3 × 0.14 mm² |
| Output Status Indication | 1 × yellow LED |
| Protection Rating | IP67 |
| Ambient Temperature | 10 °C to +85 °C |
| EMC | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, EN 55011 Class B |
| Weight | Approx. 47.6 g |
| Tightening Torque | A = 5 mm: 2 Nm; B: 3 Nm |
| Included Accessories | 2 lock nuts |
| Pack Quantity | 1 piece |
| Typical Applications | Industrial automation, machine control, metal detection, position sensing, conveyor systems, assembly machinery and factory automation |
