The IE5395 IEB31,5-BPKG/2M inductive sensor by IFM is engineered for reliable and precise non-contact detection of metallic objects in industrial automation, machine control, production equipment and factory environments. Its particularly compact M8 × 1 housing with an overall length of 20 mm makes it an excellent choice for installations where mounting space is restricted while reliable proximity detection is required.

The IE5395 uses inductive proximity sensing technology to detect metallic targets without physical contact. This makes it suitable for repetitive detection tasks such as machine position monitoring, component presence detection, metal detection, counting and automated production processes.

The sensor provides a 1.5 mm nominal sensing range, with a real sensing range of 1.5 ± 10% mm and an operating distance of 0–1.2 mm. Its compact construction and high switching frequency make it suitable for fast and space-constrained automation applications.

Key Features

IFM IE5395 inductive proximity sensor

Model: IEB31,5-BPKG/2M

1.5 mm nominal sensing range

Real sensing range: 1.5 ± 10%

Operating distance: 0–1.2 mm

PNP electrical design

Normally-open output

10–30 V DC operating voltage

4000 Hz switching frequency

100 mA permanent switching current

M8 × 1 threaded housing

20 mm overall length

Flush-mountable construction

2 m PVC connection cable

3-wire electrical connection

IP67 protection rating

-25 °C to +70 °C ambient temperature

Reverse-polarity protection

Short-circuit protection

Overload protection

High switching frequency

Compact housing for restricted installation spaces

Design & Functionality

The IE5395 is designed with a particularly short M8 × 1 threaded housing and an overall length of only 20 mm. This compact construction allows the sensor to be installed in machinery, fixtures and automation equipment where conventional sensors with longer housings may be difficult to accommodate.

The sensor is flush mountable, allowing it to be integrated neatly into compatible metal machine structures. Its compact design is particularly useful for applications with restricted installation space.

The IE5395 uses a PNP normally-open output. When a suitable metallic target enters the sensing zone, the sensor changes its switching state and provides a detection signal to compatible PLCs, controllers and industrial automation systems.

Sensing Range & Detection

The IE5395 provides a 1.5 mm sensing range, with a real sensing range of 1.5 ± 10% mm and an operating distance of 0–1.2 mm.

The specified correction factors are 1 for steel, 0.75 for stainless steel, 0.45 for brass, 0.4 for aluminium and 0.3 for copper. These values should be considered when selecting the target material and determining the effective sensing distance for an application.

PNP Normally-Open Output

The IE5395 uses a DC PNP normally-open switching output, making it suitable for compatible industrial control architectures.

When the sensor detects a metallic object, its switching output changes state and provides a detection signal to the connected PLC or automation controller.

This configuration is suitable for:

Machine position detection

Metal component detection

Object presence monitoring

Automated counting

Conveyor monitoring

Production-line control

Machine status feedback

High-Speed Switching Performance

The IE5395 provides an exceptionally high 4000 Hz switching frequency, allowing it to support fast and repetitive metal detection tasks in industrial machinery and automated production equipment.

This high switching capability makes the sensor suitable for applications where metallic targets move rapidly through the sensing area or where frequent switching signals are required.

Compact Design for Restricted Spaces

One of the main advantages of the IE5395 is its particularly short 20 mm housing.

The M8 × 1 threaded construction provides a compact installation solution for machinery, fixtures and automation equipment. This design is especially useful when surrounding components leave limited space for sensor installation.

For Industrial automation companies in UAE, this compact sensor can provide additional flexibility when designing machine structures and automated production equipment.

Industrial Automation Applications

The IE5395 can be incorporated into a wide range of Industrial Automation UAE applications requiring reliable detection of metallic objects.

Machine Position Detection

The sensor can detect the position of metallic moving parts, slides, fixtures and machine components.

Metal Component Detection

It can detect the presence or absence of metallic workpieces and components during manufacturing and assembly processes.

Conveyor Automation

The IE5395 can monitor metallic objects moving through conveyor systems and provide switching feedback to compatible control systems.

Automated Counting

The sensor can detect individual metallic objects passing a defined sensing point for automated counting and production monitoring.

Assembly Machinery

It can confirm the presence of metallic components during automated assembly and manufacturing operations.

Machine Control

The sensor can provide proximity feedback for machine-control sequences, positioning functions and automated operating cycles.

Factory Automation

Its compact housing and high switching frequency make it suitable for compatible factory automation equipment and industrial machinery.

Industrial Protection & Reliability

The IE5395 provides an IP67 protection rating, helping protect the sensor against dust and water ingress under the specified conditions. Its operating temperature range of -25 °C to +70 °C provides flexibility for a broad range of industrial environments.

The sensor also incorporates reverse-polarity, short-circuit and overload protection, supporting dependable electrical operation when installed according to the manufacturer's requirements.

2 m PVC Cable

The IE5395 is supplied with a 2 m PVC connection cable, providing a practical wired connection for installation in industrial machinery and automation equipment.

The 3-wire configuration supports the sensor's PNP switching arrangement and allows straightforward connection to compatible control systems.

Operational Advantages

1.5 mm sensing range

Reliable non-contact metal detection

PNP normally-open output

10–30 V DC operation

4000 Hz switching frequency

Compact 20 mm housing

M8 × 1 threaded construction

Flush-mountable installation

2 m PVC cable

IP67 protection

-25 °C to +70 °C operating temperature

Reverse-polarity protection

Short-circuit protection

Overload protection

High-speed switching performance

Suitable for restricted installation spaces

Suitable for industrial machinery and factory automation

Industrial Sensors Supplier UAE

The IE5395 IFM inductive sensor is a practical solution for businesses searching for Industrial Sensors, Proximity Sensors, Industrial Sensors Supplier UAE, Proximity Sensors Supplier UAE and Sensor Supplier UAE.

Its particularly short M8 × 1 housing, 1.5 mm sensing range and 4000 Hz switching frequency make it suitable for machine builders, system integrators and manufacturing facilities requiring compact and high-speed proximity detection.

Industrial Automation Solutions UAE

For Industrial Automation Suppliers UAE and industrial automation companies UAE, the IE5395 can be integrated into compatible machine-control and factory automation systems.

It can operate alongside PLCs, control panels, actuators, drives and other Industrial Automation Components UAE to provide reliable proximity feedback for machine positioning, component detection, counting, conveyor monitoring and production processes.

The IE5395 IEB31,5-BPKG/2M combines a compact 20 mm M8 × 1 housing, 1.5 mm sensing range, PNP normally-open output, 4000 Hz switching frequency, 2 m PVC cable and IP67 protection, making it a dependable inductive sensing solution for high-speed and space-constrained industrial automation applications.
