The IE5394 IEB3002BBPKG/V4A/AS inductive sensor by IFM is designed for reliable non-contact detection of metallic objects in industrial automation, machinery and factory applications. It features a 2 mm sensing range, PNP normally-open output, 10–30 V DC operation, 800 Hz switching frequency and robust V4A stainless-steel housing. Its flush-mountable M8 × 1 design, increased sensing range and resistance to oils and coolants make it a dependable choice for demanding industrial environments and applications with restricted installation space.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IE5394 IEB3002BBPKG/V4A/AS inductive sensor by IFM is engineered for dependable non-contact detection of metallic objects in industrial automation, machine tools, production equipment and factory environments. Its compact M8 × 1 threaded construction and robust V4A stainless-steel housing make it suitable for applications where reliable metal detection, durability and restricted installation space are important.
The IE5394 uses inductive proximity sensing technology to detect metallic targets without physical contact. This non-contact detection principle makes the sensor suitable for repetitive machine operations, component presence detection, position monitoring, counting and automated production processes.
The sensor provides a 2 mm nominal sensing range, with a real sensing range of 2 ± 10% mm and an operating distance of 0–1.62 mm. The increased sensing range design provides reliable detection within the specified operating zone.
IFM IE5394 inductive proximity sensor
Model: IEB3002BBPKG/V4A/AS
2 mm nominal sensing range
Real sensing range: 2 ± 10%
Operating distance: 0–1.62 mm
PNP electrical design
Normally-open output
10–30 V DC operating voltage
800 Hz switching frequency
100 mA permanent switching current
M8 × 1 threaded housing
50 mm overall length
Flush-mountable construction
V4A stainless-steel housing
LCP sensing face
M8 A-coded connector
Gold-plated connector contacts
IP65 and IP67 protection
-25 °C to +70 °C ambient temperature
Reverse-polarity protection
Short-circuit protection
Overload protection
4 yellow LED switching-status indicators
Increased sensing range
Suitable for machine tools, oils and coolants
The IE5394 features a robust V4A stainless-steel housing designed for demanding industrial environments. IFM specifies the sensor for applications involving metalworking, oils and coolants, making it suitable for machine tools and other industrial equipment exposed to these conditions.
Its M8 × 1 threaded construction and flush-mountable design allow the sensor to be integrated into suitable machine structures while keeping the installation compact. The overall housing length is approximately 50 mm.
The IE5394 uses a PNP normally-open switching output. When a suitable metallic target enters the sensing zone, the sensor switches its output and provides a detection signal to compatible PLCs, controllers and industrial automation systems.
The IE5394 provides a 2 mm sensing range with a real sensing range of 2 ± 10% mm and an operating distance of 0–1.62 mm.
Its correction factors are specified as 1 for steel, approximately 0.7 for stainless steel, 0.5 for brass, 0.4 for aluminium and 0.3 for copper. These values should be considered when selecting the target material and determining the effective sensing distance for an application.
The IE5394 uses a PNP normally-open output, making it suitable for compatible industrial control architectures.
When a metallic target is detected, the switching output changes state and provides a detection signal to the connected PLC or automation controller.
This configuration can be used for machine position feedback, metal component detection, object presence monitoring, automated counting, conveyor monitoring and production-line control.
The IE5394 incorporates an increased sensing range design. Its 2 mm nominal sensing range and specified operating distance allow reliable proximity detection in compact machine installations.
This makes the sensor suitable for applications where consistent detection of metallic machine components is required without physical contact.
The IE5394 supports a switching frequency of up to 800 Hz, allowing it to perform repetitive detection tasks in automated machinery and production equipment.
This makes it suitable for machine-control sequences, component detection, counting operations, conveyor systems and other factory automation applications where frequent switching is required.
The IE5394 can be incorporated into a wide range of Industrial Automation UAE applications requiring reliable detection of metallic objects.
Machine Tool Applications
The sensor can detect metallic machine components and provide position feedback in machine tools and automated machining equipment.
Metal Component Detection
It can detect the presence or absence of metallic workpieces and components during manufacturing and assembly processes.
Position Detection
The IE5394 can monitor the position of slides, fixtures, machine parts and other moving metallic components.
Conveyor Automation
It can detect metallic objects moving through conveyor systems and provide switching feedback to compatible control systems.
Automated Counting
The sensor can detect individual metallic objects passing a defined sensing point for automated counting and production monitoring.
Factory Automation
Its compact design and high switching frequency make it suitable for integration into compatible factory automation equipment and industrial machinery.
Machine Tools, Oils & Coolants
The sensor's robust stainless-steel housing and resistance to oils and coolants make it suitable for demanding machine-tool environments.
The IE5394 is designed for demanding industrial environments and provides IP65 and IP67 protection, with IP67 applicable when the IFM socket is correctly screwed on.
Its V4A stainless-steel housing provides robust mechanical construction, while the operating temperature range of -25 °C to +70 °C supports operation across a broad range of factory and machinery environments.
The sensor also incorporates reverse-polarity, short-circuit and overload protection, supporting dependable electrical operation when installed according to the manufacturer's requirements.
The IE5394 uses an M8 A-coded connector for connection to compatible industrial sensor cabling. The sensor includes four yellow LEDs for switching-status indication, helping technicians identify the sensor's operating state during installation, commissioning and maintenance.
2 mm sensing range
Reliable non-contact metal detection
PNP normally-open output
10–30 V DC operation
800 Hz switching frequency
Increased sensing range
Flush-mountable M8 × 1 construction
Robust V4A stainless-steel housing
50 mm overall length
M8 connector
Gold-plated connector contacts
IP65 and IP67 protection
-25 °C to +70 °C operating temperature
Four yellow LED status indicators
Reverse-polarity protection
Short-circuit protection
Overload protection
Resistance to oils and coolants
Suitable for machine tools and industrial machinery
Suitable for factory automation and industrial equipment
The IE5394 IFM inductive sensor is a practical solution for businesses searching for Industrial Sensors, Proximity Sensors, Industrial Sensors Supplier UAE, Proximity Sensors Supplier UAE and Sensor Supplier UAE.
Its compact M8 × 1 construction, V4A stainless-steel housing, increased sensing range and resistance to oils and coolants make it suitable for machine builders, system integrators and manufacturing facilities requiring dependable proximity detection.
For Industrial Automation Suppliers UAE and industrial automation companies UAE, the IE5394 can be integrated into compatible machine-control and factory automation systems.
It can operate alongside PLCs, control panels, actuators, drives and other Industrial Automation Components UAE to provide reliable proximity feedback for machine positioning, component detection, counting, conveyor monitoring and production processes.
The IE5394 IEB3002BBPKG/V4A/AS combines a 2 mm sensing range, PNP normally-open output, 800 Hz switching frequency, increased sensing range, flush-mountable M8 × 1 construction and robust V4A stainless-steel housing, making it a dependable inductive sensing solution for demanding industrial automation and machine-tool applications.
| Feature | Specification |
|---|---|
| Product Code | IE5394 |
| Manufacturer | IFM |
| Model / Part Number | IEB3002BBPKG/V4A/AS |
| Product Type | Inductive Sensor |
| Sensor Type | Inductive / Proximity Sensor |
| Electrical Design | DC PNP |
| Output Function | Normally Open (NO) |
| Operating Voltage | 10–30 V DC |
| Current Consumption | < 10 mA |
| Protection Class | III |
| Sensing Range | 2 mm |
| Real Sensing Range (Sr) | 2 ± 10% mm |
| Operating Distance | 0–1.62 mm |
| Increased Sensing Range | Yes |
| Correction Factor – Steel | 1 |
| Correction Factor – Stainless Steel | Approx. 0.7 |
| Correction Factor – Brass | Approx. 0.5 |
| Correction Factor – Aluminium | Approx. 0.4 |
| Correction Factor – Copper | Approx. 0.3 |
| Hysteresis | 1–20% of Sr |
| Switch-Point Drift | -10 to +10% of Sr |
| Maximum Voltage Drop | 2.5 V |
| Permanent Current Rating | 100 mA |
| Switching Frequency | 800 Hz |
| Reverse Polarity Protection | Yes |
| Short-Circuit Protection | Yes |
| Overload Protection | Yes |
| Housing Type | Threaded |
| Thread | M8 × 1 |
| Overall Length | 50 mm |
| Mounting | Flush mountable |
| Housing Material | Stainless Steel V4A / 316L / 1.4404 |
| Sensing Face Material | LCP |
| LED Window Material | PPSU |
| Potting Material | Oil-resistant |
| Connection | 1 × M8 connector |
| Connector Coding | A-coded |
| Connector Contacts | 3 |
| Connector Contacts Finish | Gold-plated |
| Output Status Indication | 4 × yellow LED |
| Protection Rating | IP65 / IP67 |
| Ambient Temperature | -25 °C to +70 °C |
| Application | Industrial applications / factory automation |
| Special Applications | Machine tools, oils and coolants |
| Special Feature | Increased sensing range |
| MTTF | Approx. 1393 years |
| Weight | Approx. 19.5 g |
| Included Accessories | 2 lock nuts and 2 spring washers |
| Pack Quantity | 1 piece |
| Typical Applications | Industrial automation, machine tools, metal detection, position sensing, conveyor systems, component detection and factory automation |
