Introduction

The IFM I7R209 I7R3020-FPKG/US-100-IPF is an inductive ring sensor designed for reliable non-contact detection of metallic parts passing through a defined sensing opening.

The sensor uses a static operating principle and is designed for reliable part detection and congestion monitoring in automated material-handling and feeding systems. Its ring-shaped construction creates a controlled detection area around the passing metallic component.

The I7R209 features a compact 60 × 35 × 20 mm circular housing with an internal sensing diameter of 20.1 mm. This larger ring opening allows compatible metallic parts to pass through the sensor while their presence is monitored continuously.

The sensor uses a DC PNP electrical design with a programmable normally-open or normally-closed output. It operates from a 10–35 V DC supply and supports a permanent switching current of 200 mA.

Key Features

Inductive ring sensor for metallic part detection
Static operating principle
20.1 mm internal sensing opening
2.5 mm steel-ball resolution
PNP electrical design
Normally-open / normally-closed output programmable
10–35 V DC operating voltage
200 mA permanent switching current
Less than 2 V maximum voltage drop
Maximum part speed of 35 m/s
Adjustable pulse stretching
10–150 ms pulse stretching range
Response time below 0.5 ms
Maximum fall time of 10 ms
M12 connector
Yellow switching-status LED
IP67 protection rating
-25 °C to +70 °C ambient temperature
Protection class III
Reverse-polarity protection
Short-circuit protection
Overload protection
Polyamide housing
POM sensing ring
60 × 35 × 20 mm compact construction
Suitable for part detection
Suitable for congestion monitoring
Suitable for feeding systems
Suitable for industrial automation

Application Performance

The I7R209 is designed for non-contact detection of metallic components passing through the ring opening. Its static operating principle provides reliable detection for applications where parts move through a defined sensing path.

The 20.1 mm internal sensing diameter provides a larger detection passage for compatible metallic components. This makes the sensor suitable for feed tubes, automated feeders, material-handling systems and production equipment where parts need to be detected as they pass through a controlled path.

The sensor provides a 2.5 mm steel-ball resolution, allowing detection of relatively small metallic parts when application conditions meet the specified requirements. Its maximum specified part speed is 35 m/s, supporting fast-moving material-handling and production processes.

The programmable PNP normally-open/normally-closed output provides flexibility when connecting the sensor to compatible PLCs, controllers and automation circuits. The sensor supports a permanent switching current of 200 mA.

The adjustable 10–150 ms pulse stretching function can extend short detection signals, helping connected control systems reliably register brief detection events when metallic components pass rapidly through the sensing opening.

Ring Sensor Design

The I7R209 uses a compact ring-style housing measuring 60 × 35 × 20 mm with a 20.1 mm internal opening.

Metallic components can pass through the central ring while the sensor monitors their presence. This arrangement provides a defined and repeatable detection point for automated feeding, counting and material-flow applications.

The housing is manufactured from polyamide (PA) and the sensing ring from POM. Electrical connection is provided through an M12 connector, allowing integration with compatible industrial sensor cabling.

Part Detection & Congestion Monitoring

The I7R209 is particularly suitable for applications where metallic parts move through feed tubes or guided material-handling paths.

Part detection
Congestion monitoring
Automated counting
Small metal-part detection
Feeder monitoring
Material-flow monitoring
Production-line monitoring
Assembly automation
Component presence detection
Machine control

The ring configuration allows the sensor to detect components as they pass through the central sensing opening, providing a repeatable signal for automated control systems.
