The IFM I7R204 I7R3010-FNKG/DY/US-100-INF is a high-resolution inductive ring sensor designed for reliable non-contact detection of small metallic parts passing through a sensing opening. With 0.6 mm steel-ball resolution, NPN selectable normally-open/normally-closed output, 10–35 V DC operation, dynamic detection, adjustable pulse stretching and IP67 protection, it is suitable for high-speed part detection, counting and industrial automation applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM I7R204 I7R3010-FNKG/DY/US-100-INF is a high-resolution inductive ring sensor designed for reliable non-contact detection of small metallic objects passing through a defined sensing opening.
Its ring-shaped construction creates a controlled detection zone around the passage of the metallic target. The sensor uses a dynamic operating principle, making it suitable for fast detection applications while providing reliable operation in industrial environments.
The I7R204 features a compact 60 × 35 × 20 mm circular housing with a 10.1 mm internal opening. This configuration is suitable for detecting small metallic components travelling through feeders, production equipment and automated material-handling systems.
The sensor uses an NPN electrical design with a selectable normally-open or normally-closed output. It operates from a 10–35 V DC supply and supports a permanent switching current of 200 mA.
High-resolution inductive ring sensor
Dynamic operating principle
0.6 mm steel-ball resolution
10.1 mm internal sensing opening
60 × 35 × 20 mm circular housing
NPN electrical design
Normally-open / normally-closed output selectable
10–35 V DC operating voltage
200 mA permanent switching current
2 V maximum voltage drop
Maximum part speed of 35 m/s
Adjustable pulse stretching
Pulse stretching range: 0.1–150 ms
Response time below 0.2 ms
Maximum fall time: 0.2 ms
M12 A-coded connector
Yellow switching-status LED
IP67 protection rating
-25 °C to +70 °C ambient temperature
Protection class III
Reverse-polarity protection
Short-circuit protection
Overload protection
PA housing
POM sensing ring
Suitable for high-speed small-part detection
Suitable for automated counting
Suitable for material-flow monitoring
Suitable for industrial automation
The I7R204 is designed for high-resolution detection of small metallic objects passing through its ring-shaped sensing opening. Its 0.6 mm steel-ball resolution allows detection of very small metallic targets when installed according to the specified sensing conditions.
The dynamic operating principle and response time below 0.2 ms make the sensor suitable for fast-moving metallic parts and applications where detection events occur over very short periods. The specified maximum part speed is 35 m/s.
The adjustable 0.1–150 ms pulse stretching function can extend the output signal after detection. This can help connected PLCs and controllers reliably register short detection pulses produced by rapidly moving parts.
The NPN output can be configured as normally open or normally closed, providing flexibility when integrating the sensor into compatible control circuits. The sensor supports a permanent switching current of 200 mA.
The I7R204 features a 60 × 35 × 20 mm circular housing with a 10.1 mm internal diameter. Metallic components can pass through the central opening while the sensor monitors their presence.
The ring configuration is particularly useful for automated feeders, small-part handling equipment, production machinery and counting applications where components travel through a defined detection path.
The housing is manufactured from polyamide (PA) and the sensing ring from POM. Electrical connection is provided through an M12 A-coded connector for integration with compatible industrial sensor cabling.
The I7R204 is suitable for applications where small metallic parts move rapidly through the sensing area.
Small-part counting
High-speed component detection
Metal-part presence detection
Automated feeding
Material-flow monitoring
Production-line monitoring
Assembly automation
Component sorting
Machine control
Factory automation
The combination of 0.6 mm resolution, <0.2 ms response time, 35 m/s maximum part speed and adjustable pulse stretching makes the sensor suitable for demanding automated detection applications.
The I7R204 is suitable for Industrial Automation UAE applications requiring high-resolution detection of small metallic components.
Small metal part detection
Automated counting
Part presence detection
Metal component monitoring
Material-flow monitoring
Feeder monitoring
Production-line monitoring
Assembly automation
Machine-control applications
Factory automation
For Industrial automation companies in UAE, Industrial automation companies UAE and businesses developing Industrial automation systems in UAE, the I7R204 provides a specialised ring-sensing solution for small metallic objects.
The I7R204 is an Industrial Sensor designed specifically for ring-type detection of metallic targets. It can form part of an Industrial Sensors Supplier UAE product range alongside Proximity Sensors, Photoelectric Sensors and other industrial sensing technologies.
For a Proximity Sensors Supplier UAE or Sensor Supplier UAE, the I7R204 provides high-resolution detection in applications where a conventional point-style proximity sensor may not provide the required sensing arrangement.
The I7R204 can be integrated with compatible PLCs, controllers and machine-control systems through its M12 connector.
For an Industrial Automation Supplier in UAE, Industrial Automation Suppliers UAE, Automation Products Supplier UAE or Industrial Automation Equipment UAE, it provides a specialised ring sensor for automated part detection.
The sensor can also form part of Industrial Automation Components UAE and Factory Automation Components used in manufacturing, assembly, material handling and production equipment.
The I7R204 can form part of Industrial Equipment & Supplies, Industrial Equipment & Supplies in UAE, Industrial Equipment & Supplies suppliers, Industrial Equipment in UAE and Industrial Electrical Equipment portfolios.
Its compact ring construction, high resolution and rapid response make it suitable for machinery requiring reliable monitoring of small metallic components.
The I7R204 provides an IP67 protection rating and operates within an ambient temperature range of -25 °C to +70 °C. This supports use in industrial environments where protection against dust and water ingress is required within the specified operating conditions.
The sensor also provides reverse-polarity, short-circuit and overload protection, supporting dependable electrical operation when correctly installed.
For companies providing Industrial automation solutions in UAE, the I7R204 provides a practical high-resolution ring-sensing solution for small metallic parts and fast automated processes.
Its 0.6 mm steel-ball resolution, 10.1 mm sensing opening, selectable NPN NO/NC output, 10–35 V DC operation, adjustable 0.1–150 ms pulse stretching, M12 connector and IP67 protection make it suitable for specialised part-detection, counting and machine-monitoring applications.
| Specification | Details |
|---|---|
| Product Code | I7R204 |
| Manufacturer | IFM electronic |
| Model / Part Number | I7R3010-FNKG/DY/US-100-INF |
| Product Type | Inductive Ring Sensor |
| Sensor Type | Inductive Ring / Small-Part Sensor |
| Operating Principle | Dynamic |
| Electrical Design | NPN |
| Output Function | Normally Open / Normally Closed, Selectable |
| Operating Voltage | 10–35 V DC |
| Current Consumption | <20 mA |
| Protection Class | III |
| Reverse Polarity Protection | Yes |
| Maximum Voltage Drop | 2 V |
| Permanent Switching Current | 200 mA |
| Short-Circuit Protection | Yes |
| Overload Protection | Yes |
| Resolution – Steel Ball Diameter | 0.6 mm |
| Maximum Part Speed | 35 m/s |
| Pulse Stretching | 0.1–150 ms |
| Pulse Stretching Adjustable | Yes |
| Maximum Fall Time | 0.2 ms |
| Response Time | <0.2 ms |
| Housing Type | Circular / Ring |
| Housing Dimensions | 60 × 35 × 20 mm |
| Internal Diameter | 10.1 mm |
| Housing Material | Polyamide (PA) |
| Ring Material | POM |
| Electrical Connection | 1 × M12 connector |
| Connector Coding | A-coded |
| Switching Status Indication | 1 × yellow LED |
| Protection Rating | IP67 |
| Ambient Temperature | -25 °C to +70 °C |
| MTTF | Approx. 556 years |
| Weight | Approx. 60 g |
| Pack Quantity | 1 piece |
| Typical Applications | Small metallic part detection, automated counting, feeding systems, material handling, assembly automation, production monitoring and factory automation |
