The GM705S is a fail-safe inductive sensor designed for reliable safety monitoring in industrial automation.
Its 40 x 40 x 66 mm rectangular housing provides a robust and compact installation solution.
Two OSSD outputs support dependable safety-related machine control.
The sensor is suitable for demanding factory automation applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The GM705S provides reliable non-contact detection for machine safety and automated industrial systems. Its rectangular housing is designed for stable mounting and continuous operation.
The sensor features two OSSD outputs and a DC PNP electrical design, making it suitable for integration with safety control systems. Its robust construction and IP protection help support reliable operation in industrial environments.
Fail-safe inductive detection
40 x 40 x 66 mm rectangular housing
Enable zone of 4...20 mm
2 x OSSD outputs
DC PNP electrical design
M12 connector
Gold-plated contacts
SIL 3 safety capability
Suitable for machine safety, factory automation, industrial machinery, production lines, conveyor systems and automated position monitoring.
| Specification | Details |
|---|---|
| Product Type | Fail-safe inductive sensor |
| Model | GM705S |
| Type | GIMC-4045-US/2OSSD |
| Housing | Rectangular |
| Dimensions | 40 x 40 x 66 mm |
| Enable Zone | 4...20 mm |
| Electrical Design | DC PNP |
| Output | 2 x OSSD |
| Connection | M12 connector |
| Operating Voltage | 19.2...30 V DC |
| Protection Rating | IP65, IP67 |
| Ambient Temperature | -25...60 °C |
| Safety Level | SIL 3 |
| Application | Industrial factory automation |
