The GM701S is a fail-safe inductive sensor designed for reliable safety monitoring in automated machinery.
Its rectangular 40 x 40 x 66 mm housing provides a compact installation solution.
The sensor uses two OSSD outputs for safety-related machine control.
It is suitable for continuous operation in industrial automation environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The GM701S provides dependable fail-safe detection for industrial machinery and factory automation. Its compact rectangular housing enables convenient installation while providing reliable operation during continuous machine use.
The sensor features two OSSD outputs and can be integrated with suitable safety control systems. Its robust design supports reliable machine position monitoring and safety functions.
Fail-safe inductive sensing
40 x 40 x 66 mm rectangular housing
Enable zone of 10...15 mm
2 x OSSD outputs
DC PNP electrical design
M12 connector
SIL 3 safety capability
Maintenance-free continuous operation
Suitable for machine safety, factory automation, production lines, position monitoring, conveyor systems and automated industrial equipment.
| Specification | Details |
|---|---|
| Product Type | Fail-safe inductive sensor |
| Model | GM701S |
| Type | GIMC-4030-US/2OSSD |
| Housing | Rectangular |
| Dimensions | 40 x 40 x 66 mm |
| Enable Zone | 10...15 mm |
| Electrical Design | DC PNP |
| Output | 2 x OSSD |
| Connection | M12 connector |
| Operating Voltage | 19.2...30 V DC |
| Protection Rating | IP65, IP67 |
| Ambient Temperature | -25...70 °C |
| Safety Level | SIL 3 |
| Application | Factory automation |
