The GM505S is a fail-safe inductive sensor developed for reliable machine safety and industrial automation.
Its 40 x 40 x 66 mm rectangular housing provides a compact solution for safety monitoring.
The sensor supports dependable non-contact detection during continuous machine operation.
It is suitable for factory automation and safety-related applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The GM505S is designed to provide reliable detection for industrial safety systems and automated machinery. Its rectangular housing allows practical installation in machines and production equipment.
The sensor is suitable for connection to safety relays and safety control systems. Its robust construction and high protection rating help maintain stable performance in demanding industrial environments.
Fail-safe inductive detection
40 x 40 x 66 mm housing
10...20 mm sensing range
DC PNP design
M12 connector
IP65 and IP67 protection
SIL 3 safety capability
Suitable for continuous operation
Suitable for machine safety, industrial automation, production machinery, conveyor systems, factory automation and position monitoring.
| Specification | Details |
|---|---|
| Product Type | Fail-safe inductive sensor |
| Model | GM505S |
| Type | GIMC-4035-US |
| Housing | Rectangular |
| Dimensions | 40 x 40 x 66 mm |
| Sensing Range | 10...20 mm |
| Electrical Design | DC PNP |
| Connection | M12 connector |
| Operating Voltage | 19.2...30 V DC |
| Protection Rating | IP65, IP67 |
| Ambient Temperature | -25...70 °C |
| Safety Level | SIL 3 |
| Material | PPE / die-cast zinc |
| Application | Industrial factory automation |
