The GM504S is a fail-safe inductive sensor designed for reliable safety monitoring in industrial machinery.
Its rectangular 40 x 40 x 66 mm housing provides a compact and durable installation format.
The sensor is designed for continuous operation and dependable machine safety detection.
It is suitable for factory automation and industrial safety applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The GM504S provides reliable fail-safe detection for automated machinery and industrial safety systems. Its rectangular housing is designed for stable mounting and continuous operation.
The sensor can be integrated into safety control systems to monitor machine positions and operating conditions. Its robust construction supports dependable performance in industrial environments.
Fail-safe inductive detection
40 x 40 x 66 mm rectangular housing
Enable zone of 10...15 mm
SIL 3 safety capability
DC PNP design
M12 connection
Continuous operation
Suitable for industrial factory automation
Suitable for machine safety, factory automation, position monitoring, production machinery, conveyor systems and automated equipment.
| Specification | Details |
|---|---|
| Product Type | Fail-safe inductive sensor |
| Model | GM504S |
| Type | GIMC-4030-US |
| Housing | Rectangular |
| Dimensions | 40 x 40 x 66 mm |
| Enable Zone | 10...15 mm |
| Electrical Design | DC PNP |
| Connection | M12 connector |
| Operating Voltage | 19.2...30 V DC |
| Protection Rating | IP65, IP67 |
| Ambient Temperature | -25...70 °C |
| Safety Level | SIL 3 |
| Operation | Continuous operation |
| Application | Factory automation |
