Product Overview

TH300 is a Hanyoung NUX temperature controller for monitoring and regulating process temperature. The available configuration is built around the listed sensor inputs, control method and output arrangement, with model information of TH300. ON/OFF Hysteresis: 0.1 ~ 600.0 ℃; Hysteresis: Temp. : 0.0 ~ 600.0 ℃; Control Output: S.S.R | ON : 24 V d.c., OFF : Less than 0.1 V d.c. Pulse voltage (More than load resistance 800 Ω); Current Output (S.C.R): S.C.R is not available.

For panel and process selection, the important characteristics are the input sensor type, control response, power requirements and display or communication options. Communication type: RS232C | Full duplex; Communication distance: RS232C | approx. within 10 m; Communication speed: RS232, 485/422 | 9600/19200/38400 bps; Data length: RS232, 485/422 | 7 / 8 bits.

Key Features

Key strengths of the TH300 come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.

Input: R.T.D | R.T.D (Resistance Temperature Detector) : (Pt100 Ω IEC751); Control Output: S.S.R | ON : 24 V d.c., OFF : Less than 0.1 V d.c. Pulse voltage (More than load resistance 800 Ω); Power supply voltage: 100 - 240 V a.c. (Change rate of voltage : ± 10 %); Sampling cycle: 500 ms; Power consumption: 10 VA max.

• Input: R.T.D | R.T.D (Resistance Temperature Detector) : (Pt100 Ω IEC751)
• Control Output: S.S.R | ON : 24 V d.c., OFF : Less than 0.1 V d.c. Pulse voltage (More than load resistance 800 Ω)
• Power supply voltage: 100 - 240 V a.c. (Change rate of voltage : ± 10 %)
• Sampling cycle: 500 ms
• Power consumption: 10 VA max
• Communication type: RS232C | Full duplex
• ON/OFF Hysteresis: 0.1 ~ 600.0 ℃
• Hysteresis: Temp. : 0.0 ~ 600.0 ℃
• Current Output (S.C.R): S.C.R is not available
• Retrans mission Output: Temperature | 4 - 20 mA d.c. (Load resistance : Less than 600 Ω) PV / MV / SV (Internal selection)

Technical Characteristics

The TH300 is specified by its sensor input, control output, electrical supply, sampling behaviour and accuracy. These values determine how the controller measures temperature and applies its selected control response. Retrans mission Output: Temperature | 4 - 20 mA d.c. (Load resistance : Less than 600 Ω) PV / MV / SV (Internal selection); Digital Output (D.O): Relay | 8 points (1a 8 points); Control output: Temperature | SSR (Pulse Voltage); Retrans mission Output: Temp ㆍ Humidity | 4 - 20 mA d.c., Select among PV,SV and MV (Manipulated Value).

Additional technical characteristics include Sampling cycle: 500 ms; Accuracy: Temperature | ± 0.2 % of F.S; Response delay time: RS232, 485/422 | 0 - 999 ms.

Design and Construction

The physical design of TH300 should be considered together with the installation environment and the available mounting or display arrangement. Applicable standard: EIA-RS232C, RS485/422; Dimension: 96 (W) x 96 (H); Weight: Approx. 0.85 Kg (Including packing materials); Insulation Resistance: More than 500 V d.c. 10 MΩ Power supply terminal - exterior box, Input terminal - exterior box.

Further construction and environmental details include Dielectric Strength: 2500 V a.c. 50 - 60 Hz : Power supply terminal - exterior case (F/G : Frame Ground), Input terminal - exterior case (F/G : Frame Ground), Input terminal - Input terminal; Storage Temperature: -25 ℃ ~ 70 ℃; Vibration: 10-55 Hz, amplitude : 0.75 ㎜, 3 directions 4 times, 5 min/cycle.

Integration and Operation

Integration of TH300 requires the correct sensor input, control output, supply voltage and configuration settings for the application. Protocol: RS232, 485/422 | PC LINK / PC LINK + CRC / MODBUS - RTU; Language: Korean/English English/Chinese (Simple) English/Chinese (Traditional); Communication: 1 | RS232C; Language: 1 | Korean/English.

Additional operating and interface details include Power supply voltage: 100 - 240 V a.c. (Change rate of voltage : ± 10 %); Frequency: 50 - 60 Hz; Power consumption: 10 VA max. These values provide a practical reference for wiring, setup and normal operation within the selected configuration.

Selection and Use

Choose TH300 by confirming the exact model or configuration against the required operating conditions. The available model information is TH300. Model: TH300; Scaling: V d.c. : Input scale in accordance with conversion range; Scaling: Perform scaling of the High·Low deviation range 4 - 20 mA d.c. automatically; Standard: TFT LCD 88.9 mm (3.5").

Before installation, confirm Model: Code | Description; Shock: 147 m/s², 3 directions 3 times; External power supply: Not applied. Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
