Explore performance details, construction highlights, applications, and technical information in one clear overview.
TS510 Thermal Shock Test Controller is a Hanyoung NUX temperature controller for monitoring and regulating process temperature. The available configuration is built around the listed sensor inputs, control method and output arrangement, with model information of TS510 Thermal Shock Test Controller. Input type: Measuring range (℃) | Degree; Input type: 2 types of RTD (Pt-100, KPt-100), 11 thermocouples (K, J, E, T, R, B, S, L, N, U, Wire 5-26) 4 types of DC voltage (-10 - 20 mV, 0 - 100 mV, 1 - 5 V, 0 - 30 V); Allowable input voltage: Thermocouple : ±10 V d.c. or less, DC voltage : ±33 V d.c. or less; Input type: No-voltage contact input.
For panel and process selection, the important characteristics are the input sensor type, control response, power requirements and display or communication options. Display: TFT color LCD (115.2 x 86.4 mm); Display section: 1 | Display section (5.7" TFT LCD); Communication type: 2-wire; Synchronization: Asynchronous.
Key strengths of the TS510 Thermal Shock Test Controller come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.
Input type: Measuring range (℃) | Degree; Control output: SSR output | ON : 18 V DC Pulse voltage (800 Ω or more load resistance); Power voltage: 100 - 240 V a.c. Voltage regulation ±10 %; Sampling cycle: 250 ms; Display: TFT color LCD (115.2 x 86.4 mm).
The TS510 Thermal Shock Test Controller is specified by its sensor input, control output, electrical supply, sampling behaviour and accuracy. These values determine how the controller measures temperature and applies its selected control response. ON/OFF sensing resistor: Minimum 1㏀ and less: On, maximum 10㏀ and more: Off recognition; Min. sensing time: 0.25 sec; Hysteresis: EUS(0 ~ 100 %); Contact output (DO): Up to 32 relay | A Contact | 30 V d.c. 3 A max, 250 V a.c. 3 A.
Additional technical characteristics include Control output: SSR output | ON : 18 V DC Pulse voltage (800 Ω or more load resistance); SCR output: 4 - 20 mA DC (600 Ω or less load resistance); Transmission output: Current output | 4 - 20 mA d.c..
The physical design of TS510 Thermal Shock Test Controller should be considered together with the installation environment and the available mounting or display arrangement. Weight: Approx. 1.32 kg; Dielectric strength: Between 1st and 2nd terminals : Min. 1500 V AC for 1 min Between 1st and FG terminals : Min. 1500 V AC for 1 min Between 2nd and FG terminals : Min. 1500 V AC for 1 min; Insulation resistance: 20 ㏁ or 500 V DC between power and FG terminals; Ambient temperature: 0 ~ 50 ℃.
Further construction and environmental details include Ambient humidity: 20 ~ 90 % RH (Without condensation); Ambient temperature: -20 ~ 70 ℃; Ambient humidity: 5 - 95 % RH (Without condensation).
Integration of TS510 Thermal Shock Test Controller requires the correct sensor input, control output, supply voltage and configuration settings for the application. Communication distance: Approx. 1.2 km or less; Communication speed: 9600, 19200, 38400, 57600, 115200 bps; Data Length: 7/8 bits; Protocol: PC-Link / PC-Link+SUM / MODBUS ASC / MODBUS RTU.
Additional operating and interface details include Language: Korean/English/Chinese(Simplified); Language: S | Korean, English, Chinese (simplified); Output limit: -5.00 - 105.00 %. These values provide a practical reference for wiring, setup and normal operation within the selected configuration.
Choose TS510 Thermal Shock Test Controller by confirming the exact model or configuration against the required operating conditions. The available model information is TS510 Thermal Shock Test Controller. Model: Code | Content; Sampling cycle: 250 ms; Output type: Specific value(PV), Setting value(SV), Output(MV), and random; Response Time: 0 - 100 ms.
Before installation, confirm Input•output: 1 | Input 16 points • Output 8 points (2 modules) + Power module + Control module; Power voltage: 100 - 240 V a.c. Voltage regulation ±10 %; Power frequency: 50 - 60 ㎐. Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
| Specification | Details |
|---|---|
| Input type | Measuring range (℃) | Degree |
| Thermoresistor (RTD) | Pt100 Ω | Pt-1 | -200.0 ~ 640.0 | ±0.1 % of FS ±1 Digit |
| KPt100 Ω | KPt-1 | -200.0 ~ 500.0 |
| thermocouple (TC) | K | K-0 | -200 ~ 1370 | ±0.15 % of FS ±1 digit |
| K-1 | -200.0 ~ 1370.0 | ±0.15 % of FS ±1 digit(*2) |
| J | -200.0 ~ 1200.0 | ±0.15 % of FS ±1 digit(*2) |
| E | -200.0 ~ 1000.0 | ±0.15 % of FS ±1 digit(*2) |
| T | -200.0 ~ 400.0 | ±0.15 % of FS ±1 digit(*3) |
| R | 0.0 ~ 1700.0 | ±0.15 % of FS ±1 digit(*4) |
| B | 0.0 ~ 1800.0 | ±0.15 % of FS ±1 digit(*1) |
| S | 0.0 ~ 1700.0 | ±0.15 % of FS ±1 digit(*4) |
| L | -200.0 ~ 900.0 | ±0.15 % of FS ±1 digit(*2) |
| N | -200.0 ~ 1300.0 | ±0.15 % of FS ±1 digit(*3) |
| U | -200.0 ~ 400.0 | ±0.15 % of FS ±1 digit(*3) |
| Wre 5-26 | 0.0 ~ 2300.0 | ±0.15 % of FS ±1 digit(*4) |
| DC voltage (VDC) | -10 - 20 mV | -10.00 ~ 20.00 | ±0.1 % of FS ±1 Digit |
| 0 - 100 mV | 0.00 ~ 100.00 |
| 1 - 5 V | 1.00 ~ 5.00 |
| 0 - 30 V | 0.00 ~ 30.00 |
| Power voltage | 100 - 240 V a.c. Voltage regulation ±10 % |
| Power frequency | 50 - 60 ㎐ |
| Power consumption | 30 VA max |
| Max. rating of internal fuse | 250 V a.c. |
| Dielectric strength | Between 1st and 2nd terminals : Min. 1500 V AC for 1 min Between 1st and FG terminals : Min. 1500 V AC for 1 min Between 2nd and FG terminals : Min. 1500 V AC for 1 min |
| Insulation resistance | 20 ㏁ or 500 V DC between power and FG terminals |
| Input type | 2 types of RTD (Pt-100, KPt-100), 11 thermocouples (K, J, E, T, R, B, S, L, N, U, Wire 5-26) 4 types of DC voltage (-10 - 20 mV, 0 - 100 mV, 1 - 5 V, 0 - 30 V) |
| Sampling cycle | 250 ms |
| Measured current of thermoresistor(RTD) | Approx. 0.21 mA |
| Input resistance | thermocouple : 1 ㏁ or more, DC voltage : 1 ㏁ or more |
| Allowable wire resistance | RTD : MAX. 100 Ω/wire (Except for RTDs in the range of -100.00 to 150.00, up to 10 Ω / wire) Thermoresistor : 200 Ω or less DC voltage : 2 ㏀ or less |
| Influence of wire resistance | RTD: ± 0.3 ° C / 10 Ω (note that the wiring resistance of the three wires must be the same) |
| Allowable input voltage | Thermocouple : ±10 V d.c. or less, DC voltage : ±33 V d.c. or less |
| Reference junction compensation (RJC) Temperature error | ±1.5 ℃ (0 ~ 50 ℃) |
| Detection of sensor disconnection (Burn-out) | UP-Scale for disconnection |
| Contact output (DO) | Up to 32 relay | A Contact | 30 V d.c. 3 A max, 250 V a.c. 3 A |
| B Contact | NO : 30 V d.c. 5 A max, 250 V a.c. 5 A |
| Control output | SSR output | ON : 18 V DC Pulse voltage (800 Ω or more load resistance) |
| SCR output | 4 - 20 mA DC (600 Ω or less load resistance) |
| Transmission output | Current output | 4 - 20 mA d.c. |
| Load resistance | 600 Ω or less load resistance |
| Output limit | -5.00 - 105.00 % |
| Output type | Specific value(PV), Setting value(SV), Output(MV), and random |
| Refresh interval | 250 ms |
| Max. number of input | 32 Contacts |
| Input type | No-voltage contact input |
| ON/OFF sensing resistor | Minimum 1㏀ and less: On, maximum 10㏀ and more: Off recognition |
| Min. sensing time | 0.25 sec |
| Operational conditions | During operation/Always |
| Contact function | Operation and stop/hold/step by DI ; User can define error screen. |
| Applied standard | RS485 |
| Max. connection number | 1:32 (address 1 ~ 99) |
| Communication type | 2-wire |
| Synchronization | Asynchronous |
| Communication distance | Approx. 1.2 km or less |
| Communication speed | 9600, 19200, 38400, 57600, 115200 bps |
| Data Length | 7/8 bits |
| Parity Bit | NONE / EVEN / ODD |
| Stop Bit | 1/2 bit(s) |
| Protocol | PC-Link / PC-Link+SUM / MODBUS ASC / MODBUS RTU |
| Response Time | 0 - 100 ms |
| Input | Input calibration | EUS(0 ~ 100 %) |
| Input filter (LPF) | 0 ~ 120 sec |
| Support chamber | type | Elevator type, damper type |
| Control operation | Pattern | Up to 100, Select the test type (10 types) for each pattern |
| PID Group | 4 groups of high temperature room / low temperature room, deviation PID |
| Auto tuning | Auto tuning according to target setting value |
| Proportional band | 0.00 ~ 100.00 % (For 0.00 %, ON/OFF control) |
| Integral time | 0.0 ~ 3,000 sec (OFF when 0 sec) |
| ON/OFF control | Set 0.0 to proportional band(PB) |
| Normal Open/ Normal Close | According to selection of Normal Open/ Normal Close for control output |
| Prevent overloading | ARW zone setting (50 to 1000% of proportional band) |
| A.T GAIN | 0.0 ~ 10.0 |
| Alarm setting | Alarm setting | System alarm : 8 points |
| Alarm type | Absolute high/low limit, deviation high/low limit, in range/out of range (alarm direction, hold) |
| Absolute alarm setting range | EU(0 ~ 100 %) |
| Offset information setting range | EUS(-100 ~ 100 %) |
| Hysteresis | EUS(0 ~ 100 %) |
| Display | TFT color LCD (115.2 x 86.4 mm) |
| Number of Pixels | 640 x 480 pixel |
| Back light | LED Back light |
| Life cycle of back light | Approx. 40,000 h |
| Touch type | Resistive type (4 Wires) |
| Language | Korean/English/Chinese(Simplified) |
| Internal memory | Non-volatile memory : 80 MB - Saving of 15 days at 1 S interval |
| External memory | SD card(2 GB) : Saving of 1 year at 1 S interval |
| Saving interval | 1 ~ 360 sec |
| Memory information | Program information, setting value, recovery, and temperature setting/specific/output value |
| Ambient temperature | 0 ~ 50 ℃ |
| Temperature fluctuation | 10 ℃/h or less |
| Ambient humidity | 20 ~ 90 % RH (Without condensation) |
| Magnetic field | 400 A/m or less |
| Altitude | 2,000 m or less from the sea |
| Weight | Approx. 1.32 kg |
| Ambient temperature | -20 ~ 70 ℃ |
| Temperature fluctuation | 20 ℃/h or less |
| Ambient humidity | 5 - 95 % RH (Without condensation) |
| DC voltage, Thermoresistor sensor | ± 0.003% / ° C of maximum range |
| RTD sensor | ±0.03 ℃/℃ |
| Model | Code | Content |
| TS510- | Thermal shock test controller |
| Display section | 1 | Display section (5.7" TFT LCD) |
| N | None |
| Input•output | 1 | Input 16 points • Output 8 points (2 modules) + Power module + Control module |
| 2 | Inputs 16 points and output 16 points (3 modules) + Power module + control module |
| 3 | Inputs 16 points and output 24 points (4 modules) + Power module + control module |
| N | No input / output |
| Language | S | Korean, English, Chinese (simplified) |
| No | Type | Category | Title | File |
| 1 | Manual > User Manual | Temperature Controllers | TS510 User manual |
| 1 | CAD > 3D | Temperature Controllers | TS510 (3D) |
| 1 | Software > Program | ALL | Communication Protocol Examples |
| 2 | Software > Program | Temperature Controllers | TS510 PC Program |
| 3 | Software > Program | Temperature Controllers | TS510 Graph Viewer |
| No | Mark | Category | Title | File |
| 1 | Certification > CE | Temperature Controllers | TD510 / TH510 / TS510 (EMC) |
| Between 1st and 2nd terminals | Min. 1500 V AC for 1 min |
| Between 1st and FG terminals | Min. 1500 V AC for 1 min |
| Between 2nd and FG terminals | Min. 1500 V AC for 1 min |
| DC voltage | 2 ㏀ or less |
| System alarm | 8 points |
| Non-volatile memory | 80 MB - Saving of 15 days at 1 S interval |
