Explore performance details, construction highlights, applications, and technical information in one clear overview.
Soft polyurethane tubing is designed for use in confined spaces and areas with moving parts where flexibility and durability are essential. This tubing provides smooth, low-resistance flow while maintaining structural integrity under dynamic conditions, making it ideal for applications such as equipment routing, mechanical linkages, or systems with frequent movement.
The tubing is constructed from ether-based polyurethane, a material known for its excellent water resistance and flexibility. This construction allows the tube to maintain performance in both air and water environments without degradation, while also offering superior resilience when bent around tight curves.
The tubing features a standard configuration with cut marks printed at approximately 500 mm intervals as a guide when cutting. These markings are provided for convenience only and do not guarantee precise accuracy; actual cutting should be performed according to specific application requirements.
Operating characteristics include a maximum operating pressure of 0.7MPa (at 65% RH and 20°C), a maximum vacuum capacity of -100kPa, and an operating temperature range of -20 to 60°C for air and -15 to 60°C for water—ensuring reliable performance in both ambient and humid conditions without freezing risks.
Available in five sizes and six clear colors, the tubing offers flexibility in design and application. The color options are all clear, allowing visibility of internal flow or system components, while size selection supports a range of flow and pressure needs across different industrial setups.
The tubing can be integrated directly into systems where routing along equipment is required, especially in tight or moving environments. Its soft nature reduces reaction forces at joints and moving parts, enabling seamless integration with mechanical assemblies without causing wear or stress.
| Specification | Details |
|---|---|
| Fluid medium | Air, Water (Conditional *1) |
| Max. operating pressure (65%RH at 20ºC) | 0.7MPa *2 |
| Max. vacuum | -100kPa |
| Operating temperature range | Air: -20 to 60ºC (No freezing)/ Water: -15 to 60ºC (No freezing) |
| Available options | Soft polyurethane tubing suitable for piping in confined spaces and moving parts. Ether-based polyurethane tubing with excellent water resistance. Available in 6 clear colors and 5 sizes |
| Material | Made of ether-based polyurethane with excellent water resistance, allowing use with water |
