Explore performance details, construction highlights, applications, and technical information in one clear overview.
The nominal sensing distance is 3500 mm.
The nominal sensing distance is 3500 mm. The thermal drift Sr is ±5%, with repeat accuracy of 1%.
The operating voltage is 12 - 30 VDC, with load current of 100 mA. No-load supply current is ≤50 mA and leakage current is limited to 10 µA @ 30Vcc.
Maximum ripple is 5%. Short-circuit protection is Yes. Reverse polarity protection is Yes. Surge protection is Yes.
Ingress protection is rated IP67.
The housing material is PBT. Dimensions are M30 x 1,5 / L = 98 mm and the connection is M12 Connector.
Weight is 140 g.
Tightening torque is 1,5 nm.
The operating temperature range is - 20 °C…+ 70 °C.
Storage temperature is - 35 °C…+ 70° C (Non-freezing).
The manufacturer part number is UT1B/E2-0EUL. This model is manufactured by M.D. Micro Detectors. Response time is 600 ms.
Time to availability is ≤900 ms.
For electrical integration, it provides operating voltage 12 - 30 VDC. The physical configuration includes PBT housing, dimensions M30 x 1,5 / L = 98 mm, M12 Connector connection. It is rated IP67 for an operating temperature range of - 20 °C…+ 70 °C.
| Specification | Details |
|---|---|
| Model | UT1B/E2-0EUL |
| Manufacturer part number | UT1B/E2-0EUL |
| Manufacturer | M.D. Micro Detectors |
| Response time | 600 ms |
| Weight | 140 g |
| Housing material | PBT |
| Tightening torque | 1,5 nm |
| Operating temperature | - 20 °C…+ 70 °C |
| Dimensions | M30 x 1,5 / L = 98 mm |
| Connection | M12 Connector |
| Storage temperature | - 35 °C…+ 70° C (Non-freezing) |
| Hysteresis | 1% |
| Nominal sensing distance | 3500 mm |
| Thermal drift Sr | ±5% |
| Repeat accuracy | 1% |
| Degree of protection | IP67 |
| Time to availability | ≤900 ms |
| Short-circuit protection | Yes |
| Reverse polarity protection | Yes |
| Surge protection | Yes |
| Maximum ripple | 5% |
| Operating voltage | 12 - 30 VDC |
| Load current | 100 mA |
| No-load supply current | ≤50 mA |
| Leakage current | 10 µA @ 30Vcc |
