The IFM KT6301 is an IO-Link illuminated capacitive touch sensor designed for robust industrial operator interfaces. Its stainless-steel housing provides durability, while the ergonomic soft-touch surface supports convenient operation. RGB illumination offers configurable visual feedback, and adjustable sensitivity supports different operating conditions. The compact 0.3 m PUR cable with M12 connection makes it suitable for advanced automation panels and machine controls.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The KT6301 provides intelligent touch control through capacitive sensing and IO-Link communication. Its stainless-steel housing provides a robust industrial construction, while the ergonomic soft-touch interface enables convenient operator interaction. Integrated RGB LEDs provide configurable visual feedback, and IO-Link enables digital parameterization. The compact M22 format and M12 connection support efficient machine-panel integration.
Adjustable sensitivity helps the sensor operate effectively under different conditions, including applications where gloves or moisture are present. Configurable brightness and colour provide flexible machine status indication. The 0.3 m PUR cable and M12 connection support compact installation, while the stainless-steel housing is suitable for demanding industrial environments. IO-Link provides convenient configuration and integration with compatible automation systems.
The KT6301 combines intelligent IO-Link connectivity, capacitive touch sensing and RGB illumination with durable stainless-steel construction. It offers machine builders flexible configuration of touch and indication functions while providing operators with an ergonomic interface. Its compact connection arrangement supports efficient panel wiring. It is a suitable solution for advanced industrial automation and machine-control applications.
IO-Link communication
Capacitive touch sensing
Stainless-steel housing
RGB illumination
Ergonomic soft-touch operation
Adjustable sensitivity
Adjustable brightness
Configurable LED colour
0.3 m PUR cable
M12 plug connection
Industrial operator panels
Smart automation systems
Production machinery
Packaging equipment
Assembly lines
Machine status indication
Factory automation
Process control equipment
Advanced machine interfaces
IO-Link control systems
| Specification | Details |
|---|---|
| Product Code | KT6301 |
| Model | KTMEF-EMMFFKG/US/IO |
| Product Type | IO-Link illuminated capacitive touch sensor |
| Sensing Range | Capacitive touch sensing |
| Electrical Design | IO-Link |
| Output Function | Configurable; IO-Link |
| Operating Voltage | 10–30 V DC |
| Current Consumption | Approx. 30 mA |
| Housing Material | Stainless steel 1.4305 |
| Housing Design | M22 panel-mount soft-touch design |
| Connection | 0.3 m PUR cable |
| Connector | M12 plug |
| Protection Rating | IP65 / IP67 / front IP69K |
| Protection Class | Model-specific |
| Switching Frequency | Model-specific |
| Response Time | Model-specific |
| Ambient Temperature | -40 to 85 °C |
| Installation | Panel installation |
| Mounting | M22 |
| LED Indicator | Configurable RGB LEDs |
| Short-Circuit Protection | Yes |
| Overload Protection | Yes |
| Reverse Polarity Protection | Yes |
| Weight | Model-specific |
| Additional Information | IO-Link; stainless-steel housing; compact M12 connection |
