The TM4901 is an IFM hygienic temperature sensor designed for process-temperature measurement using a Pt 100 Class A element. Its 30 mm installation length provides compact sensing for hygienic equipment. The DN50 clamp connection supports installation in larger sanitary process pipelines. The passive RTD output is designed for connection to an external evaluation unit. Stainless-steel construction, electropolished wetted surfaces and high protection support demanding food and beverage applications. IFM specifies a DN50 clamp, 30 mm installation length, 25 bar pressure rating and -40...150 °C range.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The TM4901 uses stainless-steel 316L construction for hygienic process applications. Its DN50 clamp connection is suitable for larger sanitary process piping. The 30 mm sensing length provides compact immersion. Electropolished wetted surfaces support cleanable process installations. The M12 electrical interface provides reliable connection to external evaluation electronics.
The Pt 100 Class A element provides stable temperature measurement. Its -40...150 °C range supports a wide variety of hygienic process applications. The compact 30 mm sensing length provides quick thermal response. The passive RTD output allows connection to a compatible evaluation system. T05/T09 response is approximately 1/3 seconds.
The DN50 clamp connection supports hygienic installation in larger process lines. The stainless-steel process-contact construction supports cleanable equipment. The sensor can be connected to PLC RTD inputs or external evaluation units. Gold-plated contacts support reliable electrical transmission. The design is suitable for food, beverage and sanitary process environments.
Pt 100 Class A
30 mm installation length
DN50 clamp connection
DIN 32676 / ISO 2852
-40...150 °C
25 bar pressure rating
316L stainless steel
Electropolished wetted surface
Passive RTD
M12 A-coded connector
Gold-plated contacts
IP68 / IP69K
Fast response
Hygienic design
External evaluation
Food processing
Beverage plants
Dairy processing
Brewing systems
Large sanitary pipelines
Process tanks
CIP systems
Filling systems
Liquid monitoring
Temperature control
PLC RTD systems
Hygienic automation
Thermal processing
Process skids
Industrial monitoring
| Specification | Details |
|---|---|
| Product Model | TM4901 |
| Type Code | TM-030KFEC02- /US/ |
| Sensor | Pt 100 Class A |
| Standard | DIN EN 60751 |
| Measuring Range | -40...150 °C |
| Installation Length | 30 mm |
| Probe Diameter | 6 mm |
| Process Connection | Clamp DN50 |
| Standard | DIN 32676 / ISO 2852 |
| Application | Hygienic systems |
| Media | Liquids and gases |
| Pressure Rating | 25 bar |
| Minimum Installation Depth | 15 mm |
| Accuracy | ±(0.15 K + 0.002 × |
| Response T05/T09 | 1 / 3 s |
| Output | Passive RTD |
| Housing | Cylindrical |
| Material | 316L / 1.4404 |
| Wetted Surface | Electropolished |
| Surface Finish | Ra <0.8 µm |
| Connector | M12 A-coded |
| Contacts | Gold-plated |
| Protection | IP68 / IP69K |
| Protection Class | III |
