The TD2217 is a 50 mm hygienic temperature transmitter with integrated display for reliable process temperature monitoring. It provides clear local temperature indication while transmitting process values to automation systems. The transmitter supports −50…150 °C measurement and a 4–20 mA analogue output. IO-Link communication provides digital access to configuration and diagnostics. Its stainless-steel construction is designed for demanding food and beverage processing environments. The compact design makes it suitable for tanks, piping and hygienic machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The TD2217 provides an integrated solution for temperature sensing and local process visualization. The 50 mm insertion length is appropriate for installations where sensing depth is limited. Its four-digit display allows operators to verify temperature without additional instrumentation. The transmitter can be connected to PLC and DCS systems using the analogue output. IO-Link adds smart-sensor functionality for configuration and diagnostics. The device is designed for reliable operation in hygienic industrial environments.
The sensor detects process temperature using an integrated temperature sensing element. The electronics convert the measurement into a proportional current signal. The 4–20 mA signal can be used by conventional automation equipment. IO-Link provides digital process data and parameter access. The display provides local indication at the process point. This architecture enables simultaneous local and remote temperature monitoring.
The stainless-steel housing and probe support hygienic applications. High ingress protection helps the device withstand washdown environments. The short sensing length allows compact installation. Fast response helps detect changing process temperatures quickly. Digital diagnostics assist troubleshooting and maintenance. The transmitter is suitable for continuous industrial operation.
50 mm probe
Integrated four-digit display
Pt1000 temperature measurement
−50…150 °C range
4–20 mA output
IO-Link 1.1
Stainless-steel body
IP67/IP68/IP69K
Fast dynamic response
M12 connection
Local temperature visualization
Digital parameterisation
Diagnostic support
Hygienic design
Food industry suitability
Food manufacturing
Beverage processing
Dairy applications
Brewing plants
Process piping
Tanks
Vessels
Filling equipment
CIP systems
SIP systems
Temperature control
Process monitoring
Quality assurance
PLC systems
SCADA systems
| Specification | Details |
|---|---|
| Product model | TD2217 |
| Order code | TD-050CFED06-A-ZVG/US |
| Product type | Temperature transmitter with display |
| Probe length | 50 mm |
| Measuring range | −50…150 °C |
| Factory range | −10…150 °C |
| Sensor | Pt1000 |
| Output | 4–20 mA |
| Maximum load | 300 Ω |
| Display | 4-digit |
| Display resolution | 0.1 K |
| Analogue resolution | 0.04 K |
| Accuracy | ±0.3 K + ±0.1% MS |
| Communication | IO-Link |
| IO-Link version | 1.1 |
| Communication speed | 38.4 kBaud |
| T05 response | 1 s |
| T09 response | 3 s |
| Supply | 18–32 V DC |
| Ambient temperature | −25…80 °C |
| Storage temperature | −40…100 °C |
| Protection | IP67/IP68/IP69K |
| Connection | M12 |
| Construction | Stainless steel |
| Application class | Hygienic |
