The TD2213 is a compact hygienic temperature transmitter with an integrated four-digit display. Its 50 mm probe length is suitable for applications requiring a short insertion depth and direct local temperature indication. The device measures temperatures from −50 to 150 °C and provides a standard 4–20 mA output. IO-Link communication enables advanced configuration, diagnostics and process-data access. The stainless-steel design supports hygienic food, beverage and process applications. Its fast response and high protection rating make it suitable for demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The TD2213 combines temperature measurement, local display and digital communication in one compact transmitter. Its four-digit display allows operators to monitor the process directly at the sensor. The 50 mm sensing length is useful for short process connections and compact installations. The device can communicate with automation systems through 4–20 mA and IO-Link. Its hygienic construction is suited to cleaning-intensive environments. It is designed for reliable continuous temperature monitoring.
The temperature sensing element detects the process temperature. Electronics process the signal and convert it into a proportional 4–20 mA output. The measured value is also available through IO-Link. The integrated display provides a direct local reading. IO-Link allows parameters and diagnostic information to be accessed digitally. This makes the transmitter suitable for both conventional and smart automation systems.
The integrated four-digit LED display provides clear temperature visualization. The stainless-steel construction is suited to hygienic process environments. The short probe length allows installation in compact process equipment. The M12 electrical connection supports practical wiring and maintenance. High protection ratings help protect the transmitter against water and cleaning exposure. The compact construction simplifies integration into production equipment.
The TD2213 provides reliable measurement across its specified temperature range. Its fast response supports dynamic process monitoring. The transmitter is designed for high-pressure and washdown environments. Digital diagnostics support easier troubleshooting. The robust construction reduces maintenance requirements. It is appropriate for continuous operation in food and beverage production.
50 mm insertion length
Integrated four-digit display
−50…150 °C range
4–20 mA output
IO-Link 1.1
Stainless-steel construction
Hygienic design
IP67/IP68/IP69K
Fast response
Local temperature indication
Digital diagnostics
Parameterisation
M12 connection
PLC-compatible
Food industry suitable
Food processing lines
Beverage systems
Dairy plants
Brewing systems
Tanks
Pipes
Filling machines
Packaging systems
CIP monitoring
SIP monitoring
Temperature control
Process quality monitoring
Local temperature display
PLC integration
SCADA monitoring
| Specification | Details |
|---|---|
| Product model | TD2213 |
| Order code | TD-050FFED06-A-ZVG/US |
| Product type | Temperature transmitter with display |
| Probe length | 50 mm |
| Measuring range | −50…150 °C |
| Factory setting | −10…150 °C |
| Sensor element | Pt1000 |
| Analogue output | 4–20 mA |
| Maximum load | 300 Ω |
| Display | 4-digit LED |
| Display resolution | 0.1 K |
| Analogue resolution | 0.04 K |
| Accuracy | Approx. ±0.3 K + ±0.1% MS |
| IO-Link | Yes |
| IO-Link revision | 1.1 |
| IO-Link speed | COM2 |
| Response T05 | 1 s |
| Response T09 | 3 s |
| Supply voltage | 18–32 V DC |
| Ambient temperature | −25…80 °C |
| Storage temperature | −40…100 °C |
| Protection | IP67/IP68/IP69K |
| Electrical interface | M12 |
| Construction | Stainless steel |
| Application | Hygienic process industry |
