The TCC511 is a 50 mm temperature transmitter designed for accurate process measurement with integrated sensor monitoring. Its Pt1000 measuring element provides reliable temperature measurement while the reference architecture supports detection of measurement deviations. The transmitter offers 4...20 mA analogue output and IO-Link communication for modern industrial automation systems. Its G 1/2 threaded process connection provides practical installation for process equipment. The device combines compact dimensions, diagnostic capability and robust stainless-steel construction for demanding applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The TCC511 is designed for process temperature monitoring where measurement reliability is important. Its self-monitoring functionality helps identify deviations between calibration intervals. IO-Link provides digital access to process values, parameters and diagnostics. The standard analogue output allows easy connection to PLC and control systems. The 50 mm installation length provides a balanced solution between compactness and insertion depth.
The transmitter provides a -25...160 °C measuring range. A Pt1000 element provides the primary temperature signal. The 4...20 mA analogue output can be scaled according to the control application. IO-Link communication provides additional digital process information. Calibration-check monitoring supports condition-based maintenance strategies.
The G 1/2 external thread with sealing cone provides secure process installation. The 50 mm installation length is suitable for a wide range of process connections. Stainless-steel wetted materials provide durability in liquids and gases. IP68/IP69K protection supports demanding industrial environments. Diagnostic output functionality helps identify calibration-check and sensor-error conditions.
50 mm installation length
Pt1000 temperature element
Self-monitoring capability
-25...160 °C range
4...20 mA output
IO-Link 1.1
Calibration-check monitoring
G 1/2 process connection
316L stainless-steel wetted parts
M12 A-coded connector
Food and beverage production
Dairy processing
Brewing systems
Liquid process monitoring
Gas temperature measurement
Process heating
Process cooling
PLC control systems
Quality assurance
Predictive maintenance
| No. | Specification | Details |
|---|---|---|
| 1 | Product Code | TCC511 |
| 2 | Order Code | TCC050K1ER12-A-DKG/US |
| 3 | Product Type | Temperature transmitter |
| 4 | Product Family | TCC Series |
| 5 | Measuring Element | Pt1000 |
| 6 | Reference Element | NTC |
| 7 | Measuring Range | -25...160 °C |
| 8 | Factory Setting | -10...150 °C |
| 9 | Analogue Output | 4...20 mA |
| 10 | Diagnostic Output | 1 switching output |
| 11 | Communication | IO-Link 1.1 |
| 12 | Process Connection | G 1/2 external thread |
| 13 | Sealing | Sealing cone |
| 14 | Installation Length | 50 mm |
| 15 | Probe Diameter | 6 mm |
| 16 | Pressure Rating | 160 bar |
| 17 | Media | Liquids and gases |
| 18 | Operating Voltage | 18...32 V DC |
| 19 | Current Consumption | 10 mA at 24 V |
| 20 | Protection Class | III |
| 21 | Protection Rating | IP68 / IP69K |
| 22 | Accuracy | ±0.2 K |
| 23 | Resolution | 0.05 K analogue |
| 24 | Housing | Stainless steel 316L |
| 25 | Electrical Connection | M12 A-coded |
