The IFM TAD181 temperature transmitter with drift detection is designed for accurate, reliable and self-monitoring temperature measurement in industrial and hygienic process applications. It combines a Pt1000 measuring element with an NTC reference element and backup function, allowing temperature measurement even if one element fails. The transmitter provides 4–20 mA output, configurable diagnostic functions and IO-Link communication. Its Aseptoflex Vario connection, 87.5 mm installation length and IP68/IP69K protection support demanding process environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The TAD181 is an intelligent IFM temperature transmitter developed for applications where temperature accuracy and sensor reliability are essential. It uses thermally coupled Pt1000 and NTC sensing elements with a backup function for continuous temperature measurement. The transmitter can detect sensor drift and faults and provide diagnostic information to the automation system. Its IO-Link interface also enables convenient parameterisation, process-data access and device diagnostics.
The TAD181 provides a scalable measuring range from -25 to 160 °C with a factory setting of 0 to 150 °C. Drift warning and drift alarm thresholds can be configured between 0.2 and 5 °C in 0.05 °C steps. The analogue output provides a standard 4–20 mA signal, while the configurable digital output can provide switching or diagnostic functions. The sensor has a dynamic response of approximately 3 seconds for T05 and 6 seconds for T09.
The TAD181 features a G1 external thread with Aseptoflex Vario process connection and an 87.5 mm installation length. Its 10 mm probe diameter and stainless-steel wetted construction make it suitable for industrial and hygienic process equipment. The wetted surfaces have a surface roughness of less than Ra 0.6 µm. IP68 and IP69K protection supports reliable operation in demanding environments such as food, beverage and process industries.
Pt1000 and NTC thermally coupled sensing elements
Backup temperature measurement function
Integrated drift monitoring
Drift warning and drift alarm functions
-25 to 160 °C measuring range
Scalable measuring range
4–20 mA analogue output
Configurable diagnostic output
IO-Link communication
87.5 mm installation length
10 mm probe diameter
G1 Aseptoflex Vario process connection
50 bar pressure rating
IP68 / IP69K protection
Gold-plated M12 contacts
5-point calibration certificate included
Food processing equipment
Beverage processing systems
Hygienic process equipment
Process tanks
Industrial pipelines
Liquid temperature monitoring
Gas temperature monitoring
Heating and cooling systems
Temperature control systems
Process automation
Drift monitoring
Predictive maintenance
Equipment protection
| Specification | Details |
|---|---|
| Product Code | TAD181 |
| Brand | IFM |
| Product Type | Temperature transmitter with drift detection |
| Model | TAD088KLES30-A-ZKG/US |
| Measuring Elements | 1 x Pt1000 + 1 x NTC |
| Measuring Element Design | Thermally coupled |
| Backup Function | Yes |
| Measuring Range | -25 to 160 °C |
| Temperature Range | -13 to 320 °F |
| Factory Setting | 0 to 150 °C |
| Drift Warning | 0.2 to 5 °C |
| Drift Alarm | 0.2 to 5 °C |
| Drift Setting Step | 0.05 °C |
| Resolution | 0.05 °C |
| Analogue Output | 4–20 mA |
| Digital Output | 1 configurable output |
| Diagnostic Function | Drift and fault monitoring |
| Communication | IO-Link |
| IO-Link Revision | 1.1 |
| IO-Link Transmission | COM1, 4.8 kBaud |
| Supply Voltage | 18–32 V DC |
| Current Consumption | 6 mA at 24 V |
| Electrical Design | PNP/NPN |
| Process Connection | G1 external thread, Aseptoflex Vario |
| Installation Length | 87.5 mm |
| Probe Diameter | 10 mm |
| Media | Liquids and gases |
| Pressure Rating | 50 bar |
| Minimum Installation Depth | 25 mm |
| Accuracy | ±0.2 K from -10 to 130 °C |
| Dynamic Response T05/T09 | 3 s / 6 s |
| Ambient Temperature | -25 to 70 °C |
| Storage Temperature | -40 to 85 °C |
| Protection Rating | IP68 / IP69K |
| Protection Class | III |
| Housing Material | Stainless steel, PEI, FKM |
| Wetted Parts | Stainless steel 316L / 1.4404 / 1.4435 |
| Wetted Surface Roughness | Ra <0.6 µm |
| Electrical Connection | 1 x M12, A-coded |
| Connector Contacts | Gold-plated |
| Shock Resistance | 50 g, 11 ms |
| Vibration Resistance | 20 g, 10–2000 Hz |
| MTTF | 213 years |
| Power-on Delay | 8 s |
| Integrated Watchdog | Yes |
| Manufacturer | IFM electronic |
