TA3155 is a long-probe temperature transmitter with a 200 mm installation length. It is designed for temperature measurement in mobile machines and industrial equipment. The transmitter provides a 4–20 mA analogue output and uses a G 1/4 process connection. Its extended probe provides access to deeper measurement points. The robust design supports hydraulic systems, machinery and industrial automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Product Description
TA3155 is the extended 200 mm variant of the TA31 transmitter family. Its long probe allows temperature measurement in deeper vessels and machine components. The 4–20 mA output provides compatibility with machine controllers. The M12 connection supports reliable electrical integration. Its construction is designed for demanding mobile and industrial environments.
Temperature Monitoring
The sensor continuously measures process temperature. The measured value is transmitted through the analogue output. Controllers can use this information for alarms, regulation and equipment protection. The long probe allows flexible sensing placement. This makes TA3155 suitable for applications where short probes cannot reach the process zone.
Mechanical Reliability
The transmitter uses robust materials suitable for industrial machinery. Its long stainless-steel probe provides mechanical strength. Electrical protection helps protect the transmitter against common machine faults. High environmental protection supports mobile applications. The device is designed for long-term service.
200 mm installation length
−50…150 °C
G 1/4 process connection
4–20 mA output
10–30 V DC supply
M12 connector
Pt1000 sensing platform
Stainless-steel probe
Fast response
IP68/IP69K protection
Reverse-polarity protection
Overload protection
Short-circuit protection
Vibration resistance
Shock resistance
Long insertion length
Machine automation
PLC integration
Temperature alarms
Continuous monitoring
Mobile hydraulics
Construction equipment
Agricultural machinery
Industrial tanks
Deep process points
Pumps
Compressors
Engine systems
Hydraulic power units
Machine monitoring
PLC systems
Preventive maintenance
Equipment protection
Temperature control
Mobile automation
| Specification | Details |
|---|---|
| Model | TA3155 |
| Order code | TA-200CLEM14-A-ZVG/US |
| Product type | Temperature transmitter |
| Measuring range | −50…150 °C |
| Installation length | 200 mm |
| Process connection | G 1/4 |
| Probe diameter | Approx. 6 mm |
| Sensor | Pt1000 platform |
| Output | 4–20 mA |
| Supply | 10–30 V DC |
| Connector | M12 |
| Output scaling | Configurable |
| T05 | Approx. 1 s |
| T09 | Approx. 3 s |
| Protection | IP68/IP69K |
| Reverse polarity | Yes |
| Overload | Yes |
| Short circuit | Yes |
| Wetted material | Stainless steel 316L |
| Ambient | −40…100 °C class |
| Shock resistance | High |
| Vibration resistance | High |
| EMC | Industrial |
| Mounting | G 1/4 |
| Application | Mobile/industrial |
