TA3145 is a robust temperature transmitter designed for industrial and mobile-machine temperature monitoring. Its 150 mm probe provides extended sensing depth for process and machine applications. The transmitter provides a 4–20 mA output for direct integration with controllers. Its threaded process connection supports secure installation. Stainless-steel construction, electrical protection and high environmental resistance make it suitable for demanding applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Product Description
TA3145 is designed for applications where temperature measurement must be performed deeper inside the process. The long probe provides extended reach while maintaining a compact transmitter body. Its analogue output can be integrated into PLC and machine-control systems. The robust construction supports continuous industrial operation. The transmitter is suitable for mobile machinery and general automation applications.
Temperature Measurement
The sensing element responds to changes in process temperature. Internal electronics convert the measurement into the analogue output. The 4–20 mA signal can be scaled for the required operating range. Temperature data can be used for machine protection and process control. Fast response supports dynamic operating conditions.
Reliability
TA3145 is designed for mechanical and electrical robustness. Stainless-steel wetted materials provide durability. Protection against polarity reversal and overload improves reliability. High ingress protection supports outdoor and machine environments. The transmitter is suitable for continuous monitoring.
150 mm installation length
Pt1000 temperature sensing
4–20 mA output
Threaded process connection
10–30 V DC class supply
M12 electrical connection
Stainless-steel construction
Gold-plated contacts
Fast response
IP68/IP69K protection
Reverse-polarity protection
Overload protection
Short-circuit protection
Shock resistance
Vibration resistance
Long probe
PLC compatibility
Machine-control integration
Temperature monitoring
Industrial construction
Mobile machinery
Hydraulic systems
Industrial machines
Process equipment
Pumps
Compressors
Construction equipment
Agricultural machinery
Engine systems
Machine diagnostics
PLC control
Preventive maintenance
Temperature alarms
Equipment protection
Industrial automation
| Specification | Details |
|---|---|
| Model | TA3145 |
| Order code | TA-150C5ER14-A-ZVG/US |
| Product type | Temperature transmitter |
| Sensor | Pt1000 platform |
| Installation length | 150 mm |
| Process connection | Threaded |
| Probe diameter | Approx. 6 mm |
| Output | 4–20 mA |
| Supply | 10–30 V DC class |
| Connector | M12 |
| Output scaling | Configurable |
| Response | Fast |
| T05 | Approx. 1 s |
| T09 | Approx. 3 s |
| Protection | IP68/IP69K class |
| Reverse polarity | Yes |
| Overload | Yes |
| Short circuit | Yes |
| Wetted material | Stainless steel |
| Ambient | Wide industrial range |
| Shock resistance | High |
| Vibration resistance | High |
| EMC | Industrial |
| Mounting | Threaded |
| Application | Mobile/industrial |
