TA3135 is an industrial temperature transmitter with a 150 mm installation length for deeper process temperature measurement. It uses a G 1/4 process connection and provides a standard 4–20 mA output. The extended probe allows temperature measurement deeper inside tanks and process equipment. Its robust stainless-steel construction supports demanding industrial environments. The transmitter is suitable for machinery, process equipment, pumps and industrial automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Product Description
TA3135 provides extended sensing depth for applications where a 150 mm probe is required. The transmitter converts process temperature into a standard analogue current signal. Its G 1/4 process connection supports straightforward industrial installation. The M12 electrical connection allows reliable connection to automation equipment. The device is suitable for continuous temperature monitoring.
Process Monitoring
TA3135 can measure temperature continuously in liquids and gases. The analogue output provides a proportional signal for PLC or controller systems. Temperature information can be used for alarms and process regulation. The long probe provides useful access to deeper process areas. This supports automated process monitoring and equipment protection.
Industrial Reliability
The stainless-steel probe provides mechanical durability. The transmitter is designed for industrial environments with temperature and vibration exposure. Protection functions help prevent damage from electrical faults. The M12 connection supports serviceability. Its robust design is suitable for OEM and plant installations.
150 mm installation length
−50…150 °C class range
G 1/4 process connection
4–20 mA output
10–30 V DC class supply
M12 connector
Pt1000 sensing element
Stainless steel
Fast response
IP68/IP69K class protection
Reverse-polarity protection
Overload protection
Short-circuit protection
High vibration resistance
Compact transmitter body
Long insertion probe
PLC integration
Temperature alarms
Continuous monitoring
Industrial design
Industrial tanks
Process piping
Hydraulic systems
Pump systems
Compressors
Machine tools
Plant engineering
OEM machinery
Temperature control
Process monitoring
PLC systems
SCADA
Equipment protection
Preventive maintenance
Industrial automation
| Specification | Details |
|---|---|
| Model | TA3135 |
| Order code | TA-150CLER14-A-ZVG/US |
| Product type | Temperature transmitter |
| Sensor | Pt1000 |
| Measuring range | −50…150 °C class |
| Installation length | 150 mm |
| Process connection | G 1/4 |
| Probe diameter | Approx. 6 mm |
| Output | 4–20 mA |
| Supply | 10–30 V DC class |
| Connector | M12 |
| Output | Scalable |
| Response | Fast |
| T05 | Approx. 1 s |
| T09 | Approx. 3 s |
| Protection | IP68/IP69K |
| Reverse polarity | Yes |
| Overload | Yes |
| Short circuit | Yes |
| Wetted material | Stainless steel 316L |
| Ambient | −40…100 °C class |
| Shock resistance | High |
| Vibration resistance | High |
| EMC | Industrial compliant |
| Application | Industrial/mobile |
