TA2435 is an extended industrial temperature transmitter designed for deeper process-temperature measurement. Its 100 mm installation length provides improved reach into tanks, vessels and process pipelines. The G 1/2 external thread provides a robust process connection. The transmitter combines 4...20 mA analogue output with IO-Link communication. Its long-probe design is suitable for industrial process monitoring, temperature control and automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The 100 mm installation length allows the sensing element to reach further into process media. This is useful where short probes cannot reach the required measurement location. The RTD sensing element provides stable temperature measurement. Analogue output supports conventional control systems. IO-Link enables digital process-value access and diagnostics.
The G 1/2 external thread provides secure threaded installation. The 6 mm probe maintains a compact sensing profile. Stainless-steel construction supports industrial durability. The long probe can be used in tanks and pipelines with suitable mechanical support. Correct process sealing should be selected according to application requirements.
The transmitter provides 4...20 mA output for standard PLC systems. IO-Link enables digital configuration and diagnostics. The M12 connector provides reliable electrical connectivity. The device can be integrated into SCADA and industrial IoT systems. It supports both conventional and smart-factory automation.
100 mm installation length
G 1/2 external thread
6 mm probe
4...20 mA output
IO-Link
M12 connector
Long-probe construction
Stainless-steel housing
Liquid measurement
Gas measurement
Process monitoring
Digital diagnostics
PLC integration
Temperature control
Industrial automation
Process tanks
Pipelines
Industrial vessels
Cooling systems
Heating systems
Hydraulic equipment
Pumps
Compressors
Liquid monitoring
Gas monitoring
PLC systems
Process automation
Equipment protection
Thermal management
Industrial IoT
| Specification | Details |
|---|---|
| Product Model | TA2435 |
| Type Code | TA-100CLER12-A-ZVG/US |
| Product Type | Temperature transmitter |
| Measuring Element | Model-specific |
| Accuracy | Model-specific |
| Measuring Range | Model-specific |
| Factory Setting | Model-specific |
| Installation Length | 100 mm |
| Probe Diameter | 6 mm |
| Process Connection | G 1/2 external |
| Media | Liquids and gases |
| Analogue Output | 1 |
| Output | 4...20 mA |
| Communication | IO-Link |
| Connector | M12 |
| Supply | 18...32 V DC |
| Current Consumption | <50 mA |
| Housing | Stainless steel |
| Mounting | Threaded |
| Protection | IP67/IP68/IP69K |
| IO-Link Revision | 1.1 |
| Diagnostics | Digital |
| Installation | Process mounted |
| Pack Quantity | 1 pcs |
