TA2417 is a compact industrial temperature transmitter designed for reliable process-temperature monitoring. Its 50 mm installation length provides practical immersion into process media. The G 1/2 external thread supports secure threaded installation. Analogue 4...20 mA output enables conventional PLC integration while IO-Link provides digital communication. The stainless-steel transmitter is suitable for industrial machinery, process equipment and temperature-control applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The sensing element provides stable temperature measurement for continuous process monitoring. Its 50 mm installation length supports practical positioning in process lines and equipment. The analogue signal allows straightforward connection to industrial controllers. IO-Link provides additional process data and parameter access. The transmitter is designed for reliable long-term operation.
The G 1/2 external thread provides a standard threaded process interface. The 6 mm probe allows compact sensing. Stainless-steel construction supports industrial durability. The transmitter can be mounted into compatible fittings and process ports. Correct sealing ensures reliable process installation.
TA2417 supports 4...20 mA analogue signal transmission. IO-Link enables digital configuration and diagnostics. The M12 connector simplifies field wiring. PLC and SCADA integration is straightforward. The device supports modern connected-factory temperature monitoring.
50 mm installation length
G 1/2 external thread
6 mm probe
4...20 mA output
IO-Link
M12 connector
Stainless-steel construction
Compact process design
Liquid measurement
Gas measurement
Digital diagnostics
PLC integration
Process monitoring
Temperature control
Industrial automation
Industrial machinery
Process pipelines
Cooling systems
Heating systems
Pumps
Compressors
Hydraulic equipment
Machine tools
Liquid monitoring
Gas monitoring
Process automation
PLC systems
Equipment protection
Thermal management
Industrial IoT
| Specification | Details |
|---|---|
| Product Model | TA2417 |
| Type Code | TA-050CLER12-A-ZVG/US |
| Product Type | Temperature transmitter |
| Measuring Element | Model-specific |
| Accuracy | Model-specific |
| Measuring Range | Model-specific |
| Factory Setting | Model-specific |
| Installation Length | 50 mm |
| Probe Diameter | 6 mm |
| Process Connection | G 1/2 external |
| Media | Liquids and gases |
| Analogue Output | 1 |
| Output Signal | 4...20 mA |
| Communication | IO-Link |
| Connector | M12 |
| Supply Voltage | 18...32 V DC |
| Current Consumption | <50 mA |
| Housing | Stainless steel |
| Mounting | Threaded |
| Protection | IP67/IP68/IP69K |
| IO-Link Revision | 1.1 |
| Diagnostics | Digital |
| Installation | Process mounted |
| Pack Quantity | 1 pcs |
