TA2415 is an industrial temperature transmitter designed for reliable measurement in process systems. Its 50 mm installation length provides deeper sensing than compact 30 mm variants. The G 1/2 external thread provides secure process mounting. The transmitter combines 4...20 mA analogue output with IO-Link digital communication. Its compact stainless-steel construction is suitable for liquids, gases and general industrial automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The transmitter provides stable process-temperature measurement using an RTD-based sensing element. The 50 mm installation length provides useful process immersion. The analogue output supports conventional temperature-control systems. IO-Link adds digital process data and parameterisation. This combination provides flexible monitoring and control.
The G 1/2 external thread provides a robust threaded process connection. The 6 mm probe offers a compact sensing profile. Stainless-steel construction provides durability. The transmitter can be used in process machinery and piping. Proper sealing and tightening should follow the installation requirements.
The 4...20 mA signal is suitable for standard PLC analogue inputs. IO-Link enables remote configuration and diagnostics. The M12 connector provides reliable industrial connectivity. The transmitter can be integrated into PLC, SCADA and industrial IoT systems. Its compact form simplifies machine installation.
50 mm installation length
G 1/2 external thread
6 mm probe
4...20 mA output
IO-Link
M12 connector
Stainless-steel construction
Compact transmitter
Liquid measurement
Gas measurement
Process monitoring
Digital diagnostics
PLC integration
Temperature control
Industrial automation
Process pipelines
Tanks
Cooling systems
Heating systems
Hydraulic machinery
Pumps
Compressors
Machine tools
Liquid monitoring
Gas monitoring
PLC systems
Process automation
Equipment protection
Temperature alarms
Industrial IoT
| Specification | Details |
|---|---|
| Product Model | TA2415 |
| Type Code | TA-050CLER12-A-ZVG/US |
| Product Type | Temperature transmitter |
| Measuring Element | Model-specific |
| Accuracy | Model-specific |
| Measuring Range | Model-specific |
| Factory Setting | Model-specific |
| Installation Length | 50 mm |
| Probe Diameter | 6 mm |
| Process Connection | G 1/2 external |
| Media | Liquids and gases |
| Analogue Output | 1 |
| Output | 4...20 mA |
| Communication | IO-Link |
| Connector | M12 |
| Supply | 18...32 V DC |
| Current Consumption | <50 mA |
| Housing | Stainless steel |
| Mounting | Threaded |
| Protection | IP67/IP68/IP69K |
| IO-Link Revision | 1.1 |
| Diagnostics | Digital |
| Installation | Process mounted |
| Pack Quantity | 1 pcs |
