TA2405 is a compact temperature transmitter with a 30 mm installation length and G 1/2 process connection. It uses a Pt1000 Class A measuring element for accurate temperature measurement. The transmitter supports −50…150 °C and provides a scalable 4–20 mA output. IO-Link enables digital parameterisation and process-data communication. Its stainless-steel housing provides reliable performance in industrial applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
TA2405 is designed for compact temperature measurement in industrial process systems. Its 30 mm installation length provides fast response and low installation depth. The Pt1000 Class A element offers accurate process measurement. The G 1/2 connection provides a common industrial process interface. IO-Link enables convenient digital configuration.
The Pt1000 element changes resistance according to process temperature. Electronics convert the resistance into a temperature measurement. A scalable 4–20 mA output transmits the result to the controller. IO-Link adds digital process data. This provides continuous temperature monitoring.
TA2405 uses a stainless-steel cylindrical housing and 6 mm probe. The G 1/2 process connection supports secure installation. The sensor is designed for liquids and gases. High protection ratings support demanding environments. Pressure resistance makes it suitable for industrial process applications.
Pt1000 Class A
−50…150 °C
30 mm installation length
G 1/2 connection
6 mm probe
4–20 mA
IO-Link
COM2
M12 connector
Stainless steel
High pressure resistance
0.04 K resolution
1 / 3 s response
IP67/IP68/IP69K
Reverse polarity protection
Overload protection
Short-circuit protection
PLC integration
Industrial machinery
Process piping
Pump systems
Compressor systems
Machine tools
Plant engineering
Temperature control
Process monitoring
OEM systems
PLC automation
SCADA
Equipment protection
Preventive maintenance
Industrial automation
Process quality control
| Specification | Details |
|---|---|
| Product model | TA2405 |
| Order code | TA-030CLER12-A-ZVG/US |
| Sensor | Pt1000 Class A |
| Measuring range | −50…150 °C |
| Factory setting | −50…150 °C |
| Installation length | 30 mm |
| Probe diameter | 6 mm |
| Process connection | G 1/2 external |
| Sealing | Sealing cone |
| Media | Liquids and gases |
| Pressure rating | 400 bar class |
| Output | 4–20 mA |
| Output | Scalable |
| Communication | IO-Link |
| Revision | 1.1 |
| Supply | 18–32 V DC |
| Current consumption | <50 mA |
| Resolution | 0.04 K |
| Accuracy | ±0.3 K + ±0.1% MS |
| Response | 1 / 3 s |
| Ambient | −25…80 °C |
| Storage | −40…100 °C |
| Protection | IP67/IP68/IP69K |
| Connection | M12 |
| Housing | Stainless steel |
